Network Video Recorder Pro
UNVR-Pro
A 2U-sized video recorder with (7) 2.5/3.5" HDD bays that can provide up to 60 days of storage for (24) 4K cameras or (70) Full HD cameras.
Network Video Recorder Pro
UNVR-Pro
A 2U-sized video recorder with (7) 2.5/3.5" HDD bays that can provide up to 60 days of storage for (24) 4K cameras or (70) Full HD cameras.
UNVR-PRO Specifications | |
---|---|
Mechanical | |
Dimensions | 442 × 325 × 87 mm (17.4 × 12.8 × 3.4") |
Weight | Without brackets: 9.2 kg (20.3 lb) With brackets: 9.5 kg (20.8 lb) |
Form Factor | Rackmount (2U) |
Enclosure Material | SGCC steel |
Hardware | |
Processor | Quad ARM® Cortex®-A57 @ 1.7 GHz |
Memory | 8 GB DDR4 |
Storage Bays | (7) 2.5"/3.5" HDD/SSD bays |
Max Drive Power Budget | 135W |
Max Power Consumption | 160W |
Touchscreen Display | 1.3" color touchscreen |
Networking | |
Interfaces | (1) 10G SFP+ port (1) 1G RJ45 Ethernet port |
Power | |
Power Method | Universal AC input: 100–240V AC, 3A Max, 50/60 Hz USP-RPS DC input: 11.5V DC, 13.91A |
Power Supply | Internal AC/DC, 200W |
Redundancy | USP-RPS support |
Environmental | |
Operating Temperature | -5 to 40°C (23 to 104°F) |
Operating Humidity | 5 to 95% noncondensing |
Software & Features | |
Application Suite | UniFi Protect, UniFi Access |
Camera Capacity | Up to 70 HD cameras Up to 35 2K cameras Up to 24 4K cameras |
Data Protection | RAID support |
Management Interface | Ethernet, touchscreen |
Compliance | |
Certifications | CE, FCC, IC |
NDAA Compliant | ✓ |
