Description
Overview
Protect Viewport
UFP-VIEWPORT
Easy-to-use hub for viewing Protect camera feeds on an HDMI display.
Protect Viewport
UFP-VIEWPORT
Easy-to-use hub for viewing Protect camera feeds on an HDMI display.
| UFP-VIEWPORT Specifications | |
|---|---|
| Product Type | HDMI Display Interface for UniFi Protect |
| Function | Streams UniFi Protect camera feeds to HDMI displays |
| Video Output | Up to 4K @ 30 FPS |
| Mechanical | |
| Dimensions | 157 × 52 × 37 mm (6.2 × 2.1 × 1.5") |
| Weight | Without mount: 230 g (8.1 oz) With TV mount: 252 g (8.9 oz) |
| Enclosure Material | Polycarbonate |
| Mounting Options | Wall mount TV VESA mount (M6/M8 screws) Surface mount (double-sided tape) |
| Hardware | |
| Processor | Qualcomm® QCS605 SoC |
| Memory | 4 GB LPDDR4X |
| Networking Interface | (1) 10/100/1000 Mbps RJ45 Ethernet port |
| HDMI Interface | (1) HDMI output port (supports 1080p and 4K) |
| Bluetooth | Bluetooth 5.0 with 2 dBi antenna gain |
| Button | Factory reset |
| LED Indicator | Power/status |
| Power | |
| Power Method | 802.3af PoE |
| Max Power Consumption | 9.5W |
| Environmental | |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Operating Humidity | 20 to 80% noncondensing |
| ESD/EMP Protection | Air: ±8kV / Contact: ±4kV |
| Software & Integration | |
| Management Interface | UniFi Protect (Web & Mobile) |
| System Requirements | UniFi Protect v1.13 or later |
| Mobile App Compatibility | iOS™ and Android™ |
| Compliance | |
| Certifications | FCC, IC, CE |
| NDAA Compliant | ✓ |
