Description
Overview
Power Backup
USP-RPS
950W redundant power supply for rack-mounted UniFi devices.
Power Backup
USP-RPS
950W redundant power supply for rack-mounted UniFi devices.
| USP-RPS Specifications | |
|---|---|
| Mechanical | |
| Dimensions | 442.4 × 325.6 × 43.7 mm (17.4 × 12.8 × 1.7") |
| Weight | Without brackets: 5.5 kg (12.1 lb) With brackets: 5.6 kg (12.3 lb) |
| Enclosure Material | SGCC Steel |
| Hardware Interfaces | |
| Networking Interface | (1) Gigabit Ethernet RJ45 port |
| Power Output | (6) RPS DC ports |
| Display | 1.3" color touchscreen |
| Buttons | (1) Factory reset |
| LED Indicators | System status Ethernet link/activity USP RPS activity |
| Power | |
| Power Method | Universal AC input (100–240V AC) |
| Power Supply | Internal AC/DC: 645W (54V DC output) Internal AC/DC: 350W (12V DC output) |
| Max Power Consumption | 995W |
| Max Output Power | 52V DC: 11.54A (600W) 11.5V DC: 30.44A (350W) |
| Max Output per RPS Port | 52V DC: 11.54A (600W) 11.5V DC: 30.44A (350W) |
| Environmental | |
| Operating Temperature | −5 to 45°C (23 to 113°F) |
| Operating Humidity | 10 to 90% noncondensing |
| ESD/EMP Protection | Air: ±16kV / Contact: ±12kV |
| Compliance | |
| Certifications | CE, FCC, IC |
| NDAA Compliant | ✓ |
