Overview
WAN Switch
USW-WAN
10G SFP+ WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.
Note. Use an additional USW-WAN switch for deployments with multiple ISPs.
WAN Switch
USW-WAN
10G SFP+ WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.
Note. Use an additional USW-WAN switch for deployments with multiple ISPs.
USW-WAN Specifications | |
---|---|
Form Factor | Rack mount (1U) |
Dimensions | 442.4 × 120 × 43.7 mm (17.4 × 4.72 × 1.7") |
Port Layout | 1 GbE RJ45: 1 port (1G/100M/10M) 10G SFP+: 3 ports (10G/1G) |
Redundancy | (2) AC inputs |
Switching Capacity | 20 Gbps |
Total Non-Blocking Throughput | 10 Gbps |
Forwarding Rate | 15 Mpps |
Max. Power Consumption | 13W |
Power Method | (2) Universal input, 100–240V AC, 50/60 Hz |
Power Input Method | AC input |
Power Supply | (2) AC/DC internal, 36W |
Supported Voltage Range | 100–240V AC |
Management | Ethernet |
Weight | Without mounting brackets: 2.2 kg (4.85 lb) With mounting brackets: 2.3 kg (5.1 lb) |
Enclosure Material | SGCC steel |
Mount Material | SGCC steel |
ESD Protection | Air: ±16kV, Contact: ±22kV |
Ambient Operating Temperature | -5 to 40° C (23 to 104° F) |
Ambient Operating Humidity | 10 to 90% noncondensing |
Status LEDs | Ethernet ✓, SFP+ ✓, System ✓ |
NDAA Compliant | ✓ |
Certifications | CE, FCC, IC |
Application Requirements | UniFi Network Version 9.1.119 and later |
