Description
Overview
AMAZING GAMING PROCESSORS WITH AMD 3D V-CACHE™ TECHNOLOGY
AMD Ryzen™ 7 7800X3D processor featuring AMD 3D V-Cache™ technology delivers absolute gaming performance that exceeds the highest expectations.
TECHNOLOGY THAT SAVES YOU TIME
With time-saving connectivity features and technologies, like PCIe 5.0® storage support, ultra-fast WiFi® 6E wireless, 8 cores/16 processing threads, and dedicated video accelerators, elevate your creator experience with an AMD Ryzen™ 7 7800X3D processor.
UPGRADEABLE FOR YEARS TO COME
Power. Performance. Possibility. AMD Socket AM5 motherboards deliver new features for gamers, from the speed of DDR5 memory and AMD EXPO™ technology to the increased bandwidth with PCle® 5.0, supported through 2025.
AMAZING GAMING PROCESSORS WITH AMD 3D V-CACHE™ TECHNOLOGY
AMD Ryzen™ 7 7800X3D processor featuring AMD 3D V-Cache™ technology delivers absolute gaming performance that exceeds the highest expectations.
TECHNOLOGY THAT SAVES YOU TIME
With time-saving connectivity features and technologies, like PCIe 5.0® storage support, ultra-fast WiFi® 6E wireless, 8 cores/16 processing threads, and dedicated video accelerators, elevate your creator experience with an AMD Ryzen™ 7 7800X3D processor.
UPGRADEABLE FOR YEARS TO COME
Power. Performance. Possibility. AMD Socket AM5 motherboards deliver new features for gamers, from the speed of DDR5 memory and AMD EXPO™ technology to the increased bandwidth with PCle® 5.0, supported through 2025.
| AMD Ryzen™ 7 7800X3D (100-100000910WOF) Specifications | |
|---|---|
| Core & Architecture | |
| Architecture | Zen 4 |
| Process Node | TSMC 5nm FinFET (CPU), 6nm FinFET (I/O) |
| Total Cores | 8 |
| Total Threads | 16 |
| Base Clock | 4.2 GHz |
| Max Boost Clock | Up to 5.0 GHz |
| L1 Cache | 512 KB |
| L2 Cache | 8 MB |
| L3 Cache | 96 MB (3D V-Cache) |
| Unlocked | Yes |
| Socket | AM5 |
| Memory Support | |
| Memory Type | DDR5 |
| Memory Channels | 2 |
| Max Memory Capacity | 128 GB |
| Max Memory Speed | DDR5-5200 (2x1R), DDR5-3600 (4x2R) |
| ECC Support | Yes (with motherboard support) |
| AMD EXPO™ Support | Yes |
| PCIe & I/O | |
| PCIe Version | PCIe 5.0 |
| Total PCIe Lanes | 28 (24 usable) |
| USB Support | 4× USB 3.2 Gen 2, 1× USB 2.0 |
| NVMe Support | Boot, RAID 0/1/10 |
| Thermal & Power | |
| Default TDP | 120 W |
| Max Operating Temperature | 89°C |
| Cooler Included | No (Liquid cooler recommended) |
| Integrated Graphics | |
| Graphics Model | None |
| Features & Technologies | |
| 3D V-Cache™ | Yes |
| Precision Boost 2 | Yes |
| Precision Boost Overdrive | Yes |
| Curve Optimizer | Yes |
| AMD Ryzen™ Master | Yes |
| Instruction Set Extensions | AVX, AVX2, AVX-512, FMA3, SSE4.2, SHA |
| Virtualization | AMD-V |
| Identification | |
| Model Number | 100-100000910WOF |
| Launch Date | April 6, 2023 |
