Description
Overview
ROG Astral GeForce RTX™ 5090 32GB GDDR7 OC Edition
- ROG Astral GeForce RTX™ 5090 32GB GDDR7 OC Edition - the first ROG quad-fan graphics card delivering unprecedented airflow and air pressure for optimal cooling performance
- AI Performance: 3593 AI TOPS
- Powered by the NVIDIA Blackwell architecture and DLSS 4
- OC mode: 2610 MHz (OC mode)/ 2580 MHz (Default mode)
- Quad-fan design boosts air flow and pressure by up to 20%
- Patented vapor chamber with milled heatspreader for lower GPU temperatures
- Phase-change GPU thermal pad ensures optimal heat transfer, lowering GPU temperatures for enhanced performance and reliability
- 3.8-slot design: massive heatsink and fin array optimized for airflow from the four Axial-tech fans
- Secure GPU protection with GPU Guard technology securing four corners of the GPU and GPU bracket ensures stable mounting.
- Full metal diecast shroud, frame backplate, and rear I/O bracket brace the PCB for rigidity.
- Powerful 80-amp MOSFETs help ensure enhanced performance, stability and higher overclocking potential
- Protective PCB coating guards against moisture, dust, and extreme temperatures.
- Auto-Extreme manufacturing process for precision and reliability
- GPU Tweak III software provides intuitive performance tweaking, advanced thermal controls and system monitoring
THE FINAL FRONTIER
The new ROG Astral family was inspired by the limitless expanse and beauty of the cosmos, and it is a testament to an unending dedication to exploring and defining new frontiers. In that spirit, the ROG Astral GeForce RTX 5090 introduces ROG's first quad-fan graphics card, coupled with a patented vapor chamber, increased heatsink fin density, a phase-change GPU thermal pad, towering default clock speeds, boosted power delivery, and more. These premium innovations – amplified by an eye-catching die-cast frame and metal GPU bracket – combine to deliver absolute performance that can handle even the most demanding gaming scenarios.
Engineered for Excellence
Driven by a passion for innovation and the pursuit of precision, we crafted the ROG Astral. Inspired by the universe’s wonders, it blends art and technology, achieving stellar cooling and unmated performance.
Cooling Expertise
Quad-Fan Force
A revolutionary four-fan design creates a powerful vertical airflow channel that boosts air pressure by up to 20%. This results in premium thermal performance that dramatically lowers GPU temperatures and minimizes hotspots, enabling unprecedented clock speeds.
Optimized Fin Spacing
The addition of a fourth fan permits more densely packed heatsink fins, increasing cooling potential.
Patented Vapor Chamber
A patented vapor chamber designed with milled pathways allows heatpipes to sink in without flattening, boosting heat dissipation efficiency. This innovative combo maximizes contact surface and improves thermal performance by over 10%.
MaxContact Design
MaxContact is an ASUS-exclusive manufacturing technique that effectively increases the surface area of the GPU heat spreader by 5% for improved thermal efficiency.
Phase-Change GPU Thermal Pad
By melting to effectively fill the gaps between the GPU and the thermal module, a premium phase-change GPU thermal pad provides superior thermal conductivity and enhanced heat dissipation, ensuring optimal performance and longevity for graphics cards under heavy loads.
Premium Power Delivery
Powerful 80-amp MOSFETs deliver over 35% more headroom than the standard design. This helps ensure enhanced performance, stability and higher overclocking potential.
ASUS GPU Guard & Bracket
To handle larger graphics processors, ASUS GPU Guard applies adhesive to secure all four corners to reduce the risk of cracks, while a GPU bracket helps ensure uniform mounting pressure and extra stability.
Protective PCB Coating
A protective conformal coating envelops the circuit board to help protect against short-circuits caused by moisture, dust or debris.
Auto−Extreme Technology
An automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass, ASUS Auto-Extreme technology reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption and a more reliable product overall.
Ultra Rigid Metal Case
A high-quality diecast frame, shroud, and backplate tightly brace the PCB for rigidity, and a 304 stainless steel I/O bracket plus bundled graphics card holder ensures stable mounting.
Perfect PSU for the GeForce RTX 50 Series
Patented “GPU-First” Intelligent Voltage Stabilizer
Pair with the ROG Thor III and ROG Strix Platinum Series PSU and enjoy reliable power for your graphics card. GPU-First enhances voltage stability by up to 45%, even during demanding gaming sessions and overclocking scenarios, helping to ensure peak performance for a more consistent gaming experience. Additionally, the integration of a GaN MOSFET boosts power efficiency by up to 30%.
PC Power Supply Calculator
Use our wattage calculator to estimate how much power you’ll need to fuel your rig, and then pick a compatible ROG, TUF Gaming or Prime power supply for ultimate performance.
The Ultimate in Ray Tracing and AI
RTX is the most advanced platform for full ray tracing and neural rendering technologies that are revolutionizing the ways we play and create. Over 700 games and applications use RTX to deliver realistic graphics and incredibly fast performance with cutting-edge AI features like DLSS Multi Frame Generation.
Your Creative AI-dvantage
NVIDIA Studio is your creative advantage. GeForce RTX 50 Series GPUs unlock transformative performance in video editing, 3D rendering, and graphic design. Experience RTX accelerations in top creative apps, world-class NVIDIA Studio drivers engineered and continually updated to provide maximum stability, and a suite of exclusive tools that harness the power of RTX for AI-assisted creative workflows.
Specifications
ROG Astral GeForce RTX™ 5090 32GB GDDR7 OC Edition
- ROG Astral GeForce RTX™ 5090 32GB GDDR7 OC Edition - the first ROG quad-fan graphics card delivering unprecedented airflow and air pressure for optimal cooling performance
- AI Performance: 3593 AI TOPS
- Powered by the NVIDIA Blackwell architecture and DLSS 4
- OC mode: 2610 MHz (OC mode)/ 2580 MHz (Default mode)
- Quad-fan design boosts air flow and pressure by up to 20%
- Patented vapor chamber with milled heatspreader for lower GPU temperatures
- Phase-change GPU thermal pad ensures optimal heat transfer, lowering GPU temperatures for enhanced performance and reliability
- 3.8-slot design: massive heatsink and fin array optimized for airflow from the four Axial-tech fans
- Secure GPU protection with GPU Guard technology securing four corners of the GPU and GPU bracket ensures stable mounting.
- Full metal diecast shroud, frame backplate, and rear I/O bracket brace the PCB for rigidity.
- Powerful 80-amp MOSFETs help ensure enhanced performance, stability and higher overclocking potential
- Protective PCB coating guards against moisture, dust, and extreme temperatures.
- Auto-Extreme manufacturing process for precision and reliability
- GPU Tweak III software provides intuitive performance tweaking, advanced thermal controls and system monitoring
THE FINAL FRONTIER
The new ROG Astral family was inspired by the limitless expanse and beauty of the cosmos, and it is a testament to an unending dedication to exploring and defining new frontiers. In that spirit, the ROG Astral GeForce RTX 5090 introduces ROG's first quad-fan graphics card, coupled with a patented vapor chamber, increased heatsink fin density, a phase-change GPU thermal pad, towering default clock speeds, boosted power delivery, and more. These premium innovations – amplified by an eye-catching die-cast frame and metal GPU bracket – combine to deliver absolute performance that can handle even the most demanding gaming scenarios.
Engineered for Excellence
Driven by a passion for innovation and the pursuit of precision, we crafted the ROG Astral. Inspired by the universe’s wonders, it blends art and technology, achieving stellar cooling and unmated performance.
Cooling Expertise
Quad-Fan Force
A revolutionary four-fan design creates a powerful vertical airflow channel that boosts air pressure by up to 20%. This results in premium thermal performance that dramatically lowers GPU temperatures and minimizes hotspots, enabling unprecedented clock speeds.
Optimized Fin Spacing
The addition of a fourth fan permits more densely packed heatsink fins, increasing cooling potential.
Patented Vapor Chamber
A patented vapor chamber designed with milled pathways allows heatpipes to sink in without flattening, boosting heat dissipation efficiency. This innovative combo maximizes contact surface and improves thermal performance by over 10%.
MaxContact Design
MaxContact is an ASUS-exclusive manufacturing technique that effectively increases the surface area of the GPU heat spreader by 5% for improved thermal efficiency.
Phase-Change GPU Thermal Pad
By melting to effectively fill the gaps between the GPU and the thermal module, a premium phase-change GPU thermal pad provides superior thermal conductivity and enhanced heat dissipation, ensuring optimal performance and longevity for graphics cards under heavy loads.
Premium Power Delivery
Powerful 80-amp MOSFETs deliver over 35% more headroom than the standard design. This helps ensure enhanced performance, stability and higher overclocking potential.
ASUS GPU Guard & Bracket
To handle larger graphics processors, ASUS GPU Guard applies adhesive to secure all four corners to reduce the risk of cracks, while a GPU bracket helps ensure uniform mounting pressure and extra stability.
Protective PCB Coating
A protective conformal coating envelops the circuit board to help protect against short-circuits caused by moisture, dust or debris.
Auto−Extreme Technology
An automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass, ASUS Auto-Extreme technology reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption and a more reliable product overall.
Ultra Rigid Metal Case
A high-quality diecast frame, shroud, and backplate tightly brace the PCB for rigidity, and a 304 stainless steel I/O bracket plus bundled graphics card holder ensures stable mounting.
Perfect PSU for the GeForce RTX 50 Series
Patented “GPU-First” Intelligent Voltage Stabilizer
Pair with the ROG Thor III and ROG Strix Platinum Series PSU and enjoy reliable power for your graphics card. GPU-First enhances voltage stability by up to 45%, even during demanding gaming sessions and overclocking scenarios, helping to ensure peak performance for a more consistent gaming experience. Additionally, the integration of a GaN MOSFET boosts power efficiency by up to 30%.
PC Power Supply Calculator
Use our wattage calculator to estimate how much power you’ll need to fuel your rig, and then pick a compatible ROG, TUF Gaming or Prime power supply for ultimate performance.
The Ultimate in Ray Tracing and AI
RTX is the most advanced platform for full ray tracing and neural rendering technologies that are revolutionizing the ways we play and create. Over 700 games and applications use RTX to deliver realistic graphics and incredibly fast performance with cutting-edge AI features like DLSS Multi Frame Generation.
Your Creative AI-dvantage
NVIDIA Studio is your creative advantage. GeForce RTX 50 Series GPUs unlock transformative performance in video editing, 3D rendering, and graphic design. Experience RTX accelerations in top creative apps, world-class NVIDIA Studio drivers engineered and continually updated to provide maximum stability, and a suite of exclusive tools that harness the power of RTX for AI-assisted creative workflows.
Specifications
Graphic Engine | NVIDIA® GeForce RTX™ 5090 |
AI Performance | 3593 TOPs |
Bus Standard | PCI Express 5.0 |
OpenGL | OpenGL® 4.6 |
Video Memory | 32GB GDDR7 |
Engine Clock | OC mode: 2610 MHz, Default mode: 2580 MHz (Boost clock) |
CUDA Core | 21760 |
Memory Speed | 28 Gbps |
Memory Interface | 512-bit |
Resolution | Digital Max Resolution 7680 x 4320 |
Interface | 2 x HDMI 2.1b, 3 x DisplayPort 2.1b, HDCP Support (2.3) |
Maximum Display Support | 4 |
NVLink/Crossfire Support | No |
Accessories | Speedsetup Manual, ROG Graphics Card Holder, Velcro Hook & Loop, ROG Magnet, Graphics Card Keycap, PCB Ruler, Thank You Card, Adapter Cable (1 to 4) |
Software | ASUS GPU Tweak III, MuseTree, GeForce Game Ready Driver, Studio Driver |
Dimensions | 357.6 x 149.3 x 76 mm (14.1 x 5.9 x 3 inch) |
Recommended PSU | 1000W |
Power Connectors | 1 x 16-pin |
Slot | 3.8 Slot |
AURA Sync | ARGB |
Note |
* Our wattage recommendation is based on a fully overclocked GPU and CPU system configuration. For a more tailored suggestion, please use the “Choose By Wattage” feature on our PSU product page: https://rog.asus.com/event/PSU/ASUS-Power-Supply-Units/index.html * All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets. If you do not use the latest and current specifications of ASUS products, you shall be liable for all loss and damage claimed by third party to ASUS based on false advertising or any other issues caused from using false specifications of ASUS products. * Maximum Display Support is specifically applied to simultaneous display situation. |
