Description
OVERVIEW
Catalyst 2960-X series Software FeaturesAll Catalyst 2960-X Series Switches use a single Universal Cisco IOS Software Image for all SKUs. Depending on the switch model, the Cisco IOS image automatically configures either the LAN Lite, LAN Base, or IP Lite feature set.LAN Lite models have reduced functionality and scalability for small deployments with basic requirements. Cisco Catalyst 2960-X Family of Switches are available with the LAN Base and LAN Lite feature sets and Catalyst 2960-XR Family of switches are available IP Lite feature sets.Note that each switch model is tied to a specific feature level; LAN Lite cannot be upgraded to LAN Base and LAN Base cannot be upgraded to IP Lite.
SPECIFICATIONS
Product Series
2960-X
Product Type
Ethernet Switch
Expansion Slot Type
SFP
Number of SFP Slots
4
Number of Total Expansion Slots
4
Shared SFP Slot
No
Bypass
No
LRE Port
No
Management Port
Yes
Modular
No
Number of Network (RJ-45) Ports
24
Port/Expansion Slot Details
Gigabit Ethernet
Token Ring Port
No
Total Number of Network Ports
24
USB
Yes
Manageable
Yes
Management
Web-based Management
VLAN
QoS
Syslog
Telnet
RMON I, II
SNMP v1, v2c, v3
DHCP
CLI
Ethernet Technology
Gigabit Ethernet
Media Type Supported
Twisted Pair
Network Technology
10/100/1000Base-T
Twisted Pair Cable Standard
Category 5
Flash Memory
128 MB
Memory Technology
DRAM
Standard Memory
512 MB
Layer Supported
2
Compatible Rack Unit
1U
Depth
279.4 mm
Form Factor
Rack-mountable
Height
44.5 mm
Weight (Approximate)
4.04 kg
Width
444.5 mm
Input Voltage
110 V AC
PoE (RJ-45) Port
No
Power Source
Power Supply
Redundant Power Supply Supported
Yes
MTBF
564910 Hour
