Description
OVERVIEW
Catalyst 2960-X series Software FeaturesAll Catalyst 2960-X Series Switches use a single Universal Cisco IOS Software Image for all SKUs. Depending on the switch model, the Cisco IOS image automatically configures either the LAN Lite, LAN Base, or IP Lite feature set.LAN Lite models have reduced functionality and scalability for small deployments with basic requirements. Cisco Catalyst 2960-X Family of Switches are available with the LAN Base and LAN Lite feature sets and Catalyst 2960-XR Family of switches are available IP Lite feature sets.Note that each switch model is tied to a specific feature level; LAN Lite cannot be upgraded to LAN Base and LAN Base cannot be upgraded to IP Lite.
SPECIFICATIONS
Expansion Slot Type:
SFP+
Number of SFP+ Slots:
2
Number of Total Expansion Slots:
2
Bypass:
No
LRE Port:
No
Management Port:
Yes
Modular:
No
Number of PoE (RJ-45) Ports:
48
Port/Expansion Slot Details:
10 Gigabit Ethernet
Token Ring Port:
No
Total Number of Network Ports:
48
USB:
Yes
Manageable:
Yes
Management:
Web-based Management
VLANbr>QoS
Syslog
Telnet
RMON I, II
SNMP v1, v2c, v3
DHCP
CCLI
Ethernet Technology:
10 Gigabit Ethernet
Media Type Supported: br>Twisted Pair
Network Technology:
10/100/1000Base-T
Twisted Pair Cable Standard:
Category 5
Flash Memory:
128 MB
Memory Technology:
DRAM
Standard Memory:
512 MB
Layer Supported:
2
Compatible Rack Unit:
1U
Depth:
368.3 mm
Form Factor:
Rack-mountable
Height: 4
4.5 mm
Weight (Approximate):
5.85 kg
Width:
444.5 mm
Input Voltage:
110 V AC
220 V AC
PoE (RJ-45) Port:
Yes
Power Source:
Power Supply
Redundant Power Supply Supported:
Yes
MTBF:
233370 Hour
Catalyst 2960-X series Software FeaturesAll Catalyst 2960-X Series Switches use a single Universal Cisco IOS Software Image for all SKUs. Depending on the switch model, the Cisco IOS image automatically configures either the LAN Lite, LAN Base, or IP Lite feature set.LAN Lite models have reduced functionality and scalability for small deployments with basic requirements. Cisco Catalyst 2960-X Family of Switches are available with the LAN Base and LAN Lite feature sets and Catalyst 2960-XR Family of switches are available IP Lite feature sets.Note that each switch model is tied to a specific feature level; LAN Lite cannot be upgraded to LAN Base and LAN Base cannot be upgraded to IP Lite.
SPECIFICATIONS
Expansion Slot Type:
SFP+
Number of SFP+ Slots:
2
Number of Total Expansion Slots:
2
Bypass:
No
LRE Port:
No
Management Port:
Yes
Modular:
No
Number of PoE (RJ-45) Ports:
48
Port/Expansion Slot Details:
10 Gigabit Ethernet
Token Ring Port:
No
Total Number of Network Ports:
48
USB:
Yes
Manageable:
Yes
Management:
Web-based Management
VLANbr>QoS
Syslog
Telnet
RMON I, II
SNMP v1, v2c, v3
DHCP
CCLI
Ethernet Technology:
10 Gigabit Ethernet
Media Type Supported: br>Twisted Pair
Network Technology:
10/100/1000Base-T
Twisted Pair Cable Standard:
Category 5
Flash Memory:
128 MB
Memory Technology:
DRAM
Standard Memory:
512 MB
Layer Supported:
2
Compatible Rack Unit:
1U
Depth:
368.3 mm
Form Factor:
Rack-mountable
Height: 4
4.5 mm
Weight (Approximate):
5.85 kg
Width:
444.5 mm
Input Voltage:
110 V AC
220 V AC
PoE (RJ-45) Port:
Yes
Power Source:
Power Supply
Redundant Power Supply Supported:
Yes
MTBF:
233370 Hour
