Description
Overview
Cisco Catalyst 9300 Series is the next generation of the industry’s most widely deployed stackable switching platform. Built for security, IoT, and the cloud, these network switches form the foundation for Cisco’s Software-Defined Access, our leading enterprise architecture. Cisco Catalyst 9300L switches are the Catalyst 9300 switches with fixed modules.
Specifications
Supported IOS
Network Advantage, Network Essentials
Network modules options
Fixed Modules
Stack Technology
StackWise-320
Stacking bandwidth
320 Gbps
Total number of MAC addresses
32,000
Total number of IPv4 routes (ARP plus learned routes)
32,000 (24,000 direct routes and 8000 indirect routes)
IPv4 routing entries
-
IPv6 routing entries
16,000
Multicast routing scale
8,000
QoS scale entries
5,120
ACL scale entries
5,120
Packet buffer per SKU
16 MB buffer for 24 and 48 port Gigabit Ethernet models
Flexible NetFlow (FNF) entries
64,000 flow on 24- and 48-port Gigabit Ethernet models
DRAM
8 GB
Flash
16 GB
VLAN IDs
4094
Total Switched Virtual Interfaces (SVIs)
1000
Jumbo frames
9198 bytes
Switching capacity
56 Gbps - 176 Gbps
Forwarding rate
41.66 Mpps - 130.95 Mpps
