Description
Overview
CyberPower CP700EIPFCRM1U with seamless Pure Sine Wave output provides complete protection for networking devices, security systems, and other electronic devices requiring active PFC power supply. Built in Automatic Voltage Regulation (AVR) function, this Line-Interactive UPS offers stabilized power output to connected devices. In addition, the UPS adopts CyberPower's patented GreenPower UPS™ technology, which greatly reduces UPS energy consumption and enhances its operating efficiency.
The featured data line protection with high-speed transmission safeguards networking devices against surges and spikes while supporting data transmission speed up to 1Gbps. With short-depth chassis design, the UPS significantly optimizes space in a rack enclosure and can meet different space requirements. Besides, the UPS is designed with a color LCD panel for users to quickly confirm the status and monitor the power system. This product also allows users to perform remote management of the UPS via PowerPanel Management Software.
Features
- Line-interactive UPS Topology
- Active PFC Compatible
- Automatic Voltage Regulation (AVR)
- Critical/Non-critical Load Outlets
- Color LCD Panel
- USB Connectivity Port
- PowerPanel Management Software
- Surge and Spike Protection
- Short-depth Chassis Design
- Energy Saving Technology
- Pure Sine Wave Output
- Overload Protection
- Hot-swappable Batteries
- LED Status Indicator
- High-speed Ethernet Data Transmission
- SNMP/HTTP Remote Management Capability (Optional)
- Network Protection
CyberPower CP700EIPFCRM1U with seamless Pure Sine Wave output provides complete protection for networking devices, security systems, and other electronic devices requiring active PFC power supply. Built in Automatic Voltage Regulation (AVR) function, this Line-Interactive UPS offers stabilized power output to connected devices. In addition, the UPS adopts CyberPower's patented GreenPower UPS™ technology, which greatly reduces UPS energy consumption and enhances its operating efficiency.
The featured data line protection with high-speed transmission safeguards networking devices against surges and spikes while supporting data transmission speed up to 1Gbps. With short-depth chassis design, the UPS significantly optimizes space in a rack enclosure and can meet different space requirements. Besides, the UPS is designed with a color LCD panel for users to quickly confirm the status and monitor the power system. This product also allows users to perform remote management of the UPS via PowerPanel Management Software.
Features
- Line-interactive UPS Topology
- Active PFC Compatible
- Automatic Voltage Regulation (AVR)
- Critical/Non-critical Load Outlets
- Color LCD Panel
- USB Connectivity Port
- PowerPanel Management Software
- Surge and Spike Protection
- Short-depth Chassis Design
- Energy Saving Technology
- Pure Sine Wave Output
- Overload Protection
- Hot-swappable Batteries
- LED Status Indicator
- High-speed Ethernet Data Transmission
- SNMP/HTTP Remote Management Capability (Optional)
- Network Protection
| General | |
|---|---|
| Model | CP700EIPFCRM1U |
| Topology | Line-interactive |
| Form Factor | Rackmount (1U) |
| Phase | Single Phase |
| Waveform Output | Pure Sine Wave |
| Energy Saving Technology | GreenPower UPS™ |
| Active PFC Compatible | Yes |
| Electrical Input | |
| Nominal Input Voltage | 220 / 230 / 240 Vac |
| Input Voltage Range | 165 ~ 271 Vac |
| Adjustable Voltage Range | 189 ~ 207 / 253 ~ 271 Vac |
| Input Frequency | 50 ± 3 / 60 ± 3 Hz (Auto-sensing) |
| Rated Input Current | 10 A |
| Input Connector | IEC C14 |
| Plug Style | Straight |
| Detachable Cord Type | IEC C14 x 2 |
| Cord Length | 6 ft / 1.83 m |
| Electrical Output | |
| Capacity | 700 VA / 420 W |
| Output Voltage | 230 ± 5% |
| Output Frequency | 50 ± 1% / 60 ± 1% |
| Power Factor | 0.6 |
| AVR | Single Boost |
| Overload Protection | Internal Current Limiting, Circuit Breaker |
| Total Outlets | 6 x IEC C13 |
| Battery + Surge Protected | 4 |
| Surge Only Protected | 2 |
| Critical Load Outlets | 2 |
| Non-critical Load Outlets | 2 |
| Transfer Time | 6 ms (Max 9 ms) |
| Battery | |
| Runtime (Half Load) | 9.6 minutes |
| Runtime (Full Load) | 2 minutes |
| Recharge Time | 8 hours (to 90%) |
| Start on Battery | Yes |
| User-replaceable | Yes |
| Hot-swappable | Yes |
| Battery Type | Sealed Lead-acid |
| Replacement Battery Pack | RBP0019 |
| Battery Quantity | 1 |
| Surge Protection & Filtering | |
| Surge Suppression | 450 Joules |
| Network Protection | RJ45 (1-in, 1-out) |
| Management & Communications | |
| LCD Panel | Color LCD |
| LCD Info | Power, Battery, Load, Fault & Warning |
| LCD Controls | Alarm, Input/Output, Battery Settings |
| LED Indicator | Power On |
| USB Port | 1 (HID Compliant) |
| Serial Port | Contact Signals |
| Audible Alarms | Battery Mode, Low Battery, Overload, UPS Fault |
| Included Cables | Power Cord x2, USB Cable x1 |
| Ethernet Speed | Up to 1Gbps |
| Software | PowerPanel Business (Recommended) |
| Remote Monitoring | SNMP/HTTP via optional RMCARD205 |
| Cloud Service | PowerPanel Cloud - 90 Days Free Trial |
| Physical | |
| Construction | Metal |
| Color | Silver |
| Rackmount Ears | Yes |
| Dimensions (in.) | 17.05 x 1.73 x 9.04 |
| Dimensions (mm.) | 433 x 44 x 229.7 |
| Weight | 18.3 lbs / 8.3 kg |
| Rack Height | 1U |
| Shipping Dimensions (in.) | 20.87 x 6.1 x 11.02 |
| Shipping Dimensions (mm.) | 530 x 155 x 280 |
| Shipping Weight | 19.86 lbs / 9.02 kg |
| Environmental | |
| Operating Temp | 32 ~ 104°F / 0 ~ 40°C |
| Operating Humidity | 0 ~ 95% (Non-condensing) |
| Operating Elevation | 0–9,843 ft / 0–3,000 m |
| Storage Temp | 5 ~ 113°F / -5 ~ 45°C |
| Storage Humidity | 0 ~ 95% (Non-condensing) |
| Storage Elevation | 0–49,213 ft / 0–15,000 m |
| Thermal Dissipation | 17 BTU/hr |
| Certifications | |
| Certifications | CE |
| RoHS Compliant | Yes |
