Overview
CH170 PLUS
The CH170 PLUS WH is a vertical mid-tower case with all the high-airflow features, offering flexibility for coolers and PSU options in a compact design.
CH170 PLUS
The CH170 PLUS WH is a vertical mid-tower case with all the high-airflow features, offering flexibility for coolers and PSU options in a compact design.
| Deepcool CH170 PLUS – Technical Specifications | |
|---|---|
| Product Dimensions (L × W × H) | 290 × 195 × 424.5 mm |
| Net Weight | 4.4 kg |
| Materials | ABS, SPCC, Tempered Glass |
| Motherboard Support | Mini-ITX, Micro-ATX |
| Front I/O Ports | USB 3.0 × 2, Gen2 Type-C × 1, Audio/Mic × 1 |
| 3.5" Drive Bays | 1 |
| 2.5" Drive Bays | 1 + 1 |
| Expansion Slots | 4 Slots |
| Pre-Installed Fans | None |
| Fan Support | Top: 1 × 120 mm / 1 × 140 mm (with SFX PSU) Side: 2 × 120 mm Bottom: 1 × 120 mm |
| Radiator Support | Side: 120 / 240 mm Bottom: 120 mm |
| CPU Cooler Height Limit | 164 mm |
| GPU Length Limit | 342 mm |
| Power Supply Type | ATX PS2 (max length: 140 mm), SFX, SFX-LEAN |
| EAN | 6933412765363 |
| Part Number | R-CH170-BKNGM0-G |
