DeepCool PQ1000G 1000W ATX 3.1 Fully Modular Power Supply
The DeepCool PQ1000G (Model: R-PQA00G-FD1B-JGAU-V1) is a high-performance 1000W ATX 3.1 power supply designed for modern gaming and workstation builds. Certified with 80PLUS Gold and Cybenetics Gold & A- ratings, it delivers up to 90% efficiency under typical loads. Built on the Helly platform, the PQ1000G features DC-to-DC topology, Japanese capacitors, and a 120mm fluid dynamic bearing fan for quiet, reliable operation. It includes a native 12V-2×6 cable rated for 600W, ensuring compatibility with PCIe 5.0 GPUs like the RTX 4090. Fully modular cabling and ATX12V v3.1 compliance make it ideal for next-gen systems.
DeepCool PQ1000G 1000W ATX 3.1 Fully Modular Power Supply
The DeepCool PQ1000G (Model: R-PQA00G-FD1B-JGAU-V1) is a high-performance 1000W ATX 3.1 power supply designed for modern gaming and workstation builds. Certified with 80PLUS Gold and Cybenetics Gold & A- ratings, it delivers up to 90% efficiency under typical loads. Built on the Helly platform, the PQ1000G features DC-to-DC topology, Japanese capacitors, and a 120mm fluid dynamic bearing fan for quiet, reliable operation. It includes a native 12V-2×6 cable rated for 600W, ensuring compatibility with PCIe 5.0 GPUs like the RTX 4090. Fully modular cabling and ATX12V v3.1 compliance make it ideal for next-gen systems.
| DeepCool PQ1000G – Technical Specifications | |
|---|---|
| Model | PQ1000G |
| Part Number | R-PQA00G-FD1B-JGAU-V1 |
| Rated Power | 1000W |
| Form Factor | ATX |
| Standard | ATX12V v3.1 |
| Efficiency Certification | 80PLUS Gold Cybenetics Gold Cybenetics A- (230V) |
| Platform | Helly |
| Topology | Active PFC + DC-to-DC |
| Capacitors | 100% Japanese electrolytic capacitors |
| Fan Size | 120 mm |
| Fan Bearing | Fluid Dynamic Bearing (FDB) |
| Modularity | Fully Modular |
| PCIe 5.0 Support | Native 12V-2×6 cable (600W) |
| Protections | OCP / OVP / UVP / SCP / OTP / OPP |
| Operating Voltage | 100–240V AC |
| Hold-Up Time | ≥16 ms at 75% load |
| Power Good Signal | 100–150 ms |
| Dimensions | 150 × 140 × 86 mm (W × L × H) |
| Color | Black |
| Warranty | 10 years |
