6 MP AcuSense Motorized Varifocal Dome Network Camera
- High quality imaging with 6 MP resolution
- Motorized varifocal lens for easy installation and monitoring
- Excellent low-light performance with powered-by-DarkFighter technology
- Efficient H.265+ compression technology
- Clear imaging against strong back light due to 120 dB true WDR technology
- Focus on human and vehicle targets classification based on deep learning
- Audio and alarm interface available
- BNC output available
- Water and dust resistant (IP67) and vandal proof (IK10)
6 MP AcuSense Motorized Varifocal Dome Network Camera
- High quality imaging with 6 MP resolution
- Motorized varifocal lens for easy installation and monitoring
- Excellent low-light performance with powered-by-DarkFighter technology
- Efficient H.265+ compression technology
- Clear imaging against strong back light due to 120 dB true WDR technology
- Focus on human and vehicle targets classification based on deep learning
- Audio and alarm interface available
- BNC output available
- Water and dust resistant (IP67) and vandal proof (IK10)
Hikvision DS-2CD2766G2T-IZS-BNC Specifications | |
---|---|
Model Number | DS-2CD2766G2T-IZS-BNC |
Camera Type | 6MP AcuSense Motorized Varifocal Dome Network Camera with BNC Output |
Image Sensor | 1/2.4″ Progressive Scan CMOS |
Max Resolution | 3072 × 2048 |
Lens | Motorized 2.8–12 mm varifocal lens |
Field of View | Horizontal: 108.8°–30.6°, Vertical: 60.1°–17.2°, Diagonal: 130.3°–35.1° |
Minimum Illumination | Color: 0.003 Lux @ (F1.6, AGC ON); 0 Lux with IR |
IR Range | Up to 60 meters |
WDR | 120 dB True WDR |
Shutter Speed | 1/3 s to 1/100,000 s |
Day & Night | IR cut filter |
Compression | H.265+, H.265, H.264+, H.264 |
Smart Features | Human/vehicle classification via deep learning Motion detection Tampering alarm |
Audio | Built-in microphone; audio input/output interface |
Alarm Interface | 1 input, 1 output |
Video Output | BNC analog output for test monitoring |
Storage | microSD slot (up to 512 GB) |
Network Interface | 1 × RJ45 10/100M Ethernet |
Power Supply | 12 VDC ±25%, PoE (802.3af) |
Power Consumption | Max. 8 W |
Ingress Protection | IP67 |
Vandal Resistance | IK10 |
Operating Conditions | -30°C to 60°C, ≤ 95% RH (non-condensing) |
