Description
Overview
6 MP Powered by Darkfighter Fixed Bullet Network Camera
- High quality imaging with 6 MP resolution
- Excellent low-light performance with powered-by-DarkFighter technology
- Clear imaging against strong back light due to 120 dB WDR technology
- Efficient H.265+ compression technology
- Focus on human and vehicle classification based on deep learning
- Water and dust resistant (IP67)
6 MP Powered by Darkfighter Fixed Bullet Network Camera
- High quality imaging with 6 MP resolution
- Excellent low-light performance with powered-by-DarkFighter technology
- Clear imaging against strong back light due to 120 dB WDR technology
- Efficient H.265+ compression technology
- Focus on human and vehicle classification based on deep learning
- Water and dust resistant (IP67)
| Hikvision DS-2CD2T66G2H-4I (2.8mm) Black Specifications | |
|---|---|
| Imaging and Optics | |
| Image Sensor | 1/2.4″ Progressive Scan CMOS |
| Max Resolution | 3200 × 1800 (6 MP) |
| Min Illumination | Color: 0.003 Lux @ (F1.6, AGC ON); B/W: 0 Lux with IR |
| Lens | 2.8 mm fixed lens |
| Field of View | Horizontal: 100°, Vertical: 55°, Diagonal: 118° |
| Wide Dynamic Range | 120 dB true WDR |
| IR Range | Up to 60 m |
| Smart Features | |
| AcuSense | Human and vehicle classification via deep learning |
| Event Detection | Motion detection Line crossing Intrusion detection Region entrance/exit |
| Video | |
| Compression | H.265+/H.265/H.264+/H.264 |
| Frame Rate | Up to 20 fps @ 3200 × 1800 |
| Bitrate Control | CBR/VBR |
| Network | |
| Protocols | IPv4/IPv6, TCP/IP, HTTP, HTTPS, FTP, NTP, RTSP, SNMP, SMTP, DHCP, DNS, DDNS |
| Security | HTTPS, TLS, IP filtering, password protection |
| Interface | 1 × RJ-45 10/100 Mbps Ethernet |
| General | |
| Color | Black |
| Power Supply | 12 VDC ±25%, PoE (802.3af) |
| Power Consumption | Max. 7 W |
| Operating Conditions | -30 °C to 60 °C, humidity ≤ 95% RH |
| Ingress Protection | IP67 |
| Dimensions | Approx. 105 × 290 mm |
| Weight | Approx. 1.2 kg |
