8 MP Smart hybrid light with Darkfighter S Motorized Varifocal Bullet Network Camera
- Supports Hikvision Embedded Open Platform (HEOP) and importing third party applications
- Supports 1.5 Tops computing power, 40 MB system memory, 350 MB smart RAM, and 2 GB eMMC storage for sharing resources
- High quality imaging with 8 MP resolution
- Efficient H.265+ compression technology
- Motorized varifocal lens for easy installation and monitoring
- Clear imaging against strong back light due to 130 dB WDR technology
- Focus on human and vehicle classification based on deep learning
- Smart Hybrid Light: advanced technology with long range
- Water and dust resistant (IP67) and vandal resistant (IK10)
8 MP Smart hybrid light with Darkfighter S Motorized Varifocal Bullet Network Camera
- Supports Hikvision Embedded Open Platform (HEOP) and importing third party applications
- Supports 1.5 Tops computing power, 40 MB system memory, 350 MB smart RAM, and 2 GB eMMC storage for sharing resources
- High quality imaging with 8 MP resolution
- Efficient H.265+ compression technology
- Motorized varifocal lens for easy installation and monitoring
- Clear imaging against strong back light due to 130 dB WDR technology
- Focus on human and vehicle classification based on deep learning
- Smart Hybrid Light: advanced technology with long range
- Water and dust resistant (IP67) and vandal resistant (IK10)
Hikvision DS-2CD3686G2HT-LIZSY-2.7-13.5M Specifications | |
---|---|
Model Number | DS-2CD3686G2HT-LIZSY-2.7-13.5M |
Camera Type | 8MP Smart Hybrid Light Motorized Varifocal Bullet Network Camera |
Image Sensor | 1/1.8″ Progressive Scan CMOS |
Max Resolution | 3840 × 2160 @ 30 fps |
Lens | Motorized varifocal lens, 2.7–13.5 mm |
Field of View | Horizontal: 108.1°–28.7°, Vertical: 56.1°–16.2°, Diagonal: 132.2°–33.0° |
Minimum Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON); 0 Lux with white light |
Illumination | Smart Hybrid Light (IR + White Light), up to 60 m |
WDR | 130 dB Scene-Adaptive Wide Dynamic Range |
Shutter Speed | 1/3 s to 1/100,000 s |
Day & Night | ColorVu 24/7 full-color imaging |
Smart Features | Human/vehicle classification via deep learning Motion detection Tampering alarm HEOP support for third-party applications |
Audio | Built-in microphone and speaker; two-way audio |
Alarm Interface | 1 input, 1 output |
Storage | microSD slot (up to 512 GB) |
Network Interface | 1 × RJ45 10/100M Ethernet |
Power Supply | 12 VDC ±25%, PoE+ (802.3at) |
Power Consumption | Max. 12 W |
Ingress Protection | IP67, IK10 |
Operating Conditions | -30°C to 60°C, ≤ 95% RH (non-condensing) |
