Description
Overview
The Aruba CX 6300 Switch Series is a modern, flexible, and intelligent family of AOS-CX stackable switches ideal for access, aggregation, and data center top-of-rack (TOR) deployments. With a cloud-centric design that combines a fully programmable OS with the Aruba Network Analytics Engine, the Aruba CX 6300 extends industry-leading monitoring and troubleshooting capabilities to the access layer. Support of Aruba NetEdit and the Aruba CX Mobile App verify that configurations are flawless and easy to deploy.
A powerful Aruba Gen7 ASIC architecture delivers fast, non-blocking performance, meaning your network is ready for tomorrow’s unpredictable demands. Aruba Virtual Stacking Framework (VSF) allows for stacking of up to 10 switches, providing scale and simplified management. This flexible series has built-in highspeed uplinks and supports high density IEEE 802.3bt high power PoE with HPE Smart Rate multi-gigabit Ethernet for high speed APs and IoT devices.
Specifications
Product Differentiator (long)
The Aruba CX 6300 Switch Series is a modern, flexible and intelligent family of AOS-CX stackable switches ideal for enterprise access, aggregation and ToR data center deployments. This model has 48 10/100/1000BASE-T and 4 SFP56 ports. Supports Class 4 PoE.
Power Consumption Description
88-96 W (maximum, depending on power supply)
Input Voltage
110-120/208-240VAC (JL670A PSU), 100-240V AC (JL086A and JL087A PSU)
External I/O Ports(48)
10/100/1000 BASE-T PoE+ ports supporting up to 30W per port, (4) 1/10/25/50G SFP ports
Latency
1Gbps: 2.28µSec, 10Gbps: 1.46µSec, 25Gbps: 1.90µSec, 50Gbps: 3.49µSec
Switching Capacity
496 Gbps
Stacking Capabilities
Up to 10 switches per stack
Throughput
369 Mpps
Memory and Processor
Quad Core ARM Cortex™ A72 @ 1.8GHz, 8 GBytes DDR4 32 GBytes eMMC 8 MB Shared Packet Buffer Memory
PoE Capability
48 ports of full redundancy PoE+ power with two 1600W JL670A PSUs
Management Features
Aruba AirWave Aruba Central Network Management Aruba NetEdit Command-line interface SNMP v2c/v3 RMON
Weight (imperial)
11.37 lbs
Weight (metric)
5.16 kg
Product Dimensions (imperial)
1.73 x 17.4 x 15.2 in
Product Dimensions (metric)
4.4 x 44.2 x 38.5 cm
