Description
Overview
HPE Networking Instant On Switch 8p Gigabit CL4 4p SR2.5G CL6 PoE 2p 10GBT 2p SFP+ 480W 1960
The HPE Networking Instant On Switch Series 1960 is a scalable solution for growing businesses with heavy bandwidth requirements and empowers your network to meet your business growing needs. With increased bandwidth, simplified network management, and the ability to handle multiple devices, it provides the ideal solution for your business.
Features
Maximize your HPE Networking Instant On Switch 1960
What's New
- Simplify network management by stacking up to four Instant On 1960 switches and managing them through one single IP address. Stacking supported via local and cloud-managed stacking modes.
- Smart-managed layer 2+ Ethernet access switch series ready to deploy in 12-port, 24-port, and 48-port for non-PoE and PoE (supports Class 4 and Class 6 PoE) models.
- The Networking Instant On 1960 aggregation switches comes with twelve 10 GBase-T and four SFP+ ports, providing 10 G connectivity to servers, network storage devices and access switches alike.
- For environments with heavy bandwidth needs, 10 GBase-T and SFP+ uplink ports deliver lightning-fast network speeds and nearly eliminates traffic bottlenecks.
- HPE Networking Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely.
HPE Networking Instant On Switch 8p Gigabit CL4 4p SR2.5G CL6 PoE 2p 10GBT 2p SFP+ 480W 1960
The HPE Networking Instant On Switch Series 1960 is a scalable solution for growing businesses with heavy bandwidth requirements and empowers your network to meet your business growing needs. With increased bandwidth, simplified network management, and the ability to handle multiple devices, it provides the ideal solution for your business.
Features
Maximize your HPE Networking Instant On Switch 1960
What's New
- Simplify network management by stacking up to four Instant On 1960 switches and managing them through one single IP address. Stacking supported via local and cloud-managed stacking modes.
- Smart-managed layer 2+ Ethernet access switch series ready to deploy in 12-port, 24-port, and 48-port for non-PoE and PoE (supports Class 4 and Class 6 PoE) models.
- The Networking Instant On 1960 aggregation switches comes with twelve 10 GBase-T and four SFP+ ports, providing 10 G connectivity to servers, network storage devices and access switches alike.
- For environments with heavy bandwidth needs, 10 GBase-T and SFP+ uplink ports deliver lightning-fast network speeds and nearly eliminates traffic bottlenecks.
- HPE Networking Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely.
| HPE Aruba Networking Instant On 1960 (S0F35A) Specifications | |
|---|---|
| General Information | |
| Switch Type | Smart Managed Layer 2+ Ethernet Switch |
| Form Factor | 1U Rack-mountable |
| Stacking | Up to 4 switches (local or cloud-managed) |
| Ports & Interfaces | |
| 1G Ports | 8× RJ-45 10/100/1000BASE-T PoE+ (Class 4) |
| 2.5G Ports | 4× RJ-45 2.5GBASE-T PoE++ (Class 6) |
| 10GBASE-T Ports | 2× RJ-45 10GBASE-T |
| SFP+ Ports | 2× 10GbE SFP+ |
| Console Port | 1× USB-C |
| USB Host | 1× USB Type-A |
| Performance | |
| Switching Capacity | 116 Gbps |
| Forwarding Rate | 172 Mpps |
| MAC Address Table | 16,000 entries |
| Routing Table | 992 static entries |
| Packet Buffer | 1.5 MB |
| Latency | 100 Mbps: < 4.1 µs 1 Gbps: < 1.8 µs 2.5 Gbps: < 6.7 µs 10 Gbps: < 2.8 µs |
| Power & PoE | |
| PoE Budget | 480 W total |
| Power Supply | Internal AC PSU |
| Max Power Rating | 635 W @ 100–127V, 623 W @ 200–240V |
| Idle Power | 34–40 W |
| Processor & Memory | |
| CPU | ARM Cortex-A9 @ 800 MHz |
| RAM | 1 GB DDR3 |
| Flash | 512 MB NAND |
| Environmental | |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -40°C to 70°C |
| Humidity | 15% to 95% (non-condensing) |
| Altitude | Up to 10,000 ft (3,000 m) |
| MTBF | 40.8 years |
| Certifications | |
| Safety | EN/IEC 62368-1, UL 62368-1, CSA C22.2 No. 62368-1 |
| EMC | CE, FCC Class A, VCCI, BSMI |
| Management & Features | |
| Management | Instant On mobile app, cloud portal, local web GUI |
| Switch Type | Smart-managed, Layer 2+ with static routing |
| Warranty | |
| Coverage | Limited Lifetime Warranty |
