Description
Overview
MS120GP
20-Port Gigabit Rackmount Switch with 16-Port PoE+
- 16× Gigabit PoE+ RJ45 ports, 2× Gigabit non-PoE RJ45 ports, and 2× Gigabit SFP slots
- High PoE power budget with up to 30 W for each PoE port and 192 W* for all PoE ports
- Working with IEEE 802.3af/at compliant PDs
- Up to 250m data and power transmitting range under Extend Mode**
- Priority mode for ports 1–4 to guarantees the quality of sensitive applications like video monitor
- Isolation Mode allows one-click client traffic separation for higher security and performance
- PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
- Plug and Play. No configuration or central management required.
MS120GP
20-Port Gigabit Rackmount Switch with 16-Port PoE+
- 16× Gigabit PoE+ RJ45 ports, 2× Gigabit non-PoE RJ45 ports, and 2× Gigabit SFP slots
- High PoE power budget with up to 30 W for each PoE port and 192 W* for all PoE ports
- Working with IEEE 802.3af/at compliant PDs
- Up to 250m data and power transmitting range under Extend Mode**
- Priority mode for ports 1–4 to guarantees the quality of sensitive applications like video monitor
- Isolation Mode allows one-click client traffic separation for higher security and performance
- PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
- Plug and Play. No configuration or central management required.
| Mercusys MS120GP Switch Specifications | |
|---|---|
| Hardware Features | |
| Ports | • 16× Gigabit PoE+ RJ45 Ports • 2× Gigabit non-PoE RJ45 ports • 2× Gigabit SFP Slots |
| PoE Standard | IEEE 802.3af/at |
| PoE Power Budget | 120 W |
| Switching Capacity | 36 Gbps |
| Packet Forwarding Rate | 26.78 Mpps |
| MAC Address Table | 8K |
| Packet Buffer | 2 Mbit |
| Fan Quantity | 1 |
| Power Supply | External Power Adapter |
| Mounting | Desktop / Rack Mountable |
| Dimensions (W × D × H) | 294 × 180 × 44 mm |
| Software Features | |
| Switch Type | Unmanaged |
| PoE Management | Auto Detection |
| Flow Control | IEEE 802.3x |
| Port Isolation | Yes |
| QoS | Yes |
| Environment | |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | −40°C to 70°C (−40°F to 158°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Storage Humidity | 5% to 90% RH (non-condensing) |
| Others | |
| Certifications | CE, FCC, RoHS |
| Package Contents | • MS120GP Switch • Power Adapter • Rackmount Kit • Quick Installation Guide |
