| Connectivity |
|
| Signal Input |
HDMI 1.4 x 2, DisplayPort 1.2 x 1, USB-C 3.2 Gen 1 x 1 (upstream, Power Delivery up to 65W) |
| Sync Input |
Separate Sync |
| Audio (In/Out) |
Audio out |
| USB |
USB 3.2 x 4 (with 1 fast charge B.C 1.2) |
| HDCP |
HDCP 1.4 (HDMI / DisplayPort / USB-C) |
| Picture/Display |
|
| Panel Size |
31.5 inch / 80 cm |
| Aspect Ratio |
16:9 |
| LCD Panel Type |
VA LCD |
| Backlight Type |
W-LED system |
| Pixel Pitch |
0.2724 x 0.2724 mm |
| Brightness |
300 cd/m² |
| Display Colors |
16.7 M |
| Color Gamut (Typical) |
NTSC 97.4%, sRGB 122%
|
| Contrast Ratio (Typical) |
3000:1 |
| SmartContrast |
Mega Infinity DCR |
| Response Time (Typical) |
4 ms (Gray to Gray)* |
| Viewing Angle |
178º (H) / 178º (V) @ C/R > 10 |
| Picture Enhancement |
SmartImage game |
| Maximum Resolution |
2560 x 1440 @ 75 Hz* |
| Effective Viewing Area |
697.344 (H) x 392.256 (V) mm |
| Scanning Frequency |
30 - 114 kHz (H) / 48 - 75 Hz (V) |
| sRGB |
Yes |
| Flicker-Free |
Yes |
| Pixel Density |
93.24 PPI |
| LowBlue Mode |
Yes |
| Display Screen Coating |
Anti-Glare, 3H, Haze 25% |
| MPRT |
1 ms |
| EasyRead |
Yes |
| AMD FreeSync™ Technology |
Yes |
| USB |
|
| Power Delivery |
USB PD version 3.0 |
| Super Speed |
Data and Video transfer |
| DP |
Built-in Display Port Alt mode |
| USB-C Max. Power Delivery |
Up to 65W (5V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A) |
| USB-C |
Reversible plug connector |
| Convenience |
|
| Built-in Speakers |
5 W x 2 |
| Plug & Play Compatibility |
DDC/CI, Mac OS X, sRGB, Windows 10 / 8.1 / 8 / 7 |
| User Convenience |
Power On/Off, Menu, Volume, Input, SmartImage Game |
| OSD Languages |
Multiple languages (including English, French, German, Japanese, etc.) |
| Other Convenience |
Kensington lock, VESA mount (100x100mm) |
| Stand |
|
| Tilt |
-5/20 degree |
| Power |
|
| Power Supply |
Internal, 100-240VAC, 50-60Hz |
| Off Mode |
0.3 W (typ.) |
| On Mode |
46.3 W (typ.) |
| Standby Mode |
0.5 W (typ.) |
| Power LED Indicator |
Operation - White, Standby mode- White (blinking) |
| Dimensions |
|
| Packaging (WxHxD) |
930 x 517 x 162 mm |
| Product without Stand (WxHxD) |
715 x 420 x 62 mm |
| Product with Stand (max height) |
715 x 514 x 248 mm |
| Weight |
|
| Product with Packaging |
11.57 kg |
| Product with Stand |
8.89 kg |
| Product without Stand |
7.21 kg |
| Operating Conditions |
|
| Altitude |
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
| Temperature Range (Operation) |
0 to 40 °C |
| MTBF |
50,000 hrs (excluding backlight) |
| Relative Humidity |
20%-80 % |
| Temperature Range (Storage) |
-20 to 60 °C |
| Sustainability |
|
| Environmental and Energy |
RoHS |
| Recyclable Packaging Material |
100 % |
| Specific Substances |
Mercury free, PVC / BFR free housing |
| Compliance and Standards |
|
| Regulatory Approvals |
CB, CE Mark, CU-EAC, EAEU RoHS, FCC Class B, ICES-003, TUV/ISO9241-307, TUV-BAUART, MEPS, RCM |
| Cabinet |
|
| Color |
Black |
| Finish |
Textured |
