QNAP 2-Bay QuTS Hero Xeon E-2136 NAS Diskless

QNAPSKU: TS-H1283XU-RP-E2136-32G

Availability:

❌ Back Order - Contact Us for ETA

Price:
Sale price$6,480.00
Contact Us for ETA

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Description

The QuTS hero NAS TS-h1283XU-RP is powered by an Intel® Xeon® E processor with up to 128 GB DDR4 Error Correcting Code (ECC) memory to deliver server-grade performance with dependable reliability. Running the brand new QuTS hero operating system that incorporates ZFS, the TS-h1283XU-RP supports near-limitless snapshots, SnapSync, block-level inline data deduplication, and inline data compression. The TS-h1283XU-RP helps your business achieve reliable service-level agreement performance, whether in a mission-critical file server, virtualization server, VDI, collaborative video editing, or efficient file backup and recovery applications.

  • 1

    DDR4 ECC memory detects and then corrects single-bit memory errors, demonstrating high reliability for crucial applications.

  • 2

    Pre-installed with a dual-port 10GbE RJ45 adapter and a dual-port 10GbE SFP+ adapter for bandwidth-demanding applications.

  • 3

    PCIe expandability allows for 10GbE/25GbE/40GbE adapters, QM2 cards, or Fibre Channel cards to increase application performance.

  • 4

    SSD cache acceleration improves random read/write performance to meet IOPS-demanding applications.

  • 5

    Supports virtualization storage for VMware®, Citrix®, Microsoft® Hyper-V®, Windows Server® 2019, and hosts virtual machines and containers.

  • 6

    QTS App Center includes feature-rich apps for expanding NAS applications without extra costs.

Intel® Xeon® E processors deliver extraordinary performance

Powered by an Intel® Xeon® E-2236 6 cores/12 threads 3.4 GHz processor (Burst up to 4.8 GHz), the TS-h1283XU-RP features enormous computing power for boosting virtual machine performance. Combined with up to 128 GB DDR4 ECC memory and a redundant power supply, the TS-h1283XU-RP delivers server-grade performance and dependable reliability for rugged enterprise IT environments as a cost-efficient NAS solution.

ECC memory prevents data corruption to assure reliability

The TS-h1283XU-RP uses ECC memory that can detect and correct single-bit memory errors as they occur to prevent downtime and data loss, which is essential for always-on, mission-critical, server-grade applications. The TS-h1283XU-RP supports dual-channel DDR4 memory in four Long-DIMM slots. When using paired memory modules, the TS-h1283XU-RP can leverage the power of dual-channel architecture to boost performance. You also customize the TS-h1283XU-RP memory configuration (supports up to 128 GB RAM) for greater performance to tackle dynamically-changing workloads, such as virtualization applications.

Server-grade hardware: Sturdy and expandable

The TS-h1283XU-RP features outstanding hardware and expandable architecture, enabling optimal performance and flexibility to meet business application diversification demands.

ZFS-based QuTS hero operating system enhances NAS performance and data integrity

QuTS hero combines the app-based QTS with the 128-bit ZFS file system to provide flexible storage management, comprehensive data protection, and optimized performance to tackle the complexity and performance demands of modern IT. From storage management, virtualization, to collaborative media workflows, QuTS hero streamlines your business-critical tasks.

  • Data integrity is key

    QuTS hero’s self-healing ensures data integrity and reliability. Write Once, Read Many (WORM) is also supported.

  • Data reduction improves storage efficiency and performance

    Inline data deduplication, compression, and compaction reduce file size to conserve storage capacity and optimize performance.

  • Multi-level cache technology

    Main memory read cache (L1 ARC), SSD second-level read cache (L2 ARC), and ZFS Intent Log (ZIL) for synchronous transactions with power fail protection are simultaneously supported to boost performance and security.

  • RAID Z enables robust data protection

    Multiple RAID levels allow flexible capacity utilization. RAID Triple Parity and Triple Mirror deliver higher levels of data protection.

  • QSAL (QNAP SSD Antiwear Leveling) enhances data protection

    RAID-level SSD lifespan is automatically and regularly detected to prevent simultaneous SSD failure, improving your data protection and system reliability.

  • App Center ecosystem extends NAS functionality

    Apps for backup/sync, virtual machines/containers, content management, productivity, and more features can be used to expand the application potential of the TS-h1283XU-RP.

Tiered storage configuration for a QuTS hero NAS

Basic requirements for setup are similar to QTS. We recommend you to follow these steps to acquire optimal storage efficiency and performance for QuTS hero.

Real-time SnapSync ensures minimal RPO with real-time disaster recovery

Real-time SnapSync ensures that both the primary and secondary NAS maintain identical data. When data is written to the source, it is immediately written to the destination. If the primary NAS goes offline, IT staff can simply adjust the privilege settings of the secondary NAS to ensure continuous operations. SnapSync provides the strongest support for nonstop business operations and helps users to reduce the risk of data loss.

The TS-h1283XU-RP also supports snapshots and remote backup to help organizations accomplish routine backup tasks cost-effectively and efficiently.

  • Snapshots multiply backup protection

    Attain peace of mind with near-limitless, instant snapshots. Copy-on-write technology makes snapshot creation almost instantaneous without affecting ongoing data writing. Snapshot Replica replicates snapshot files to the backup NAS, simplifying data protection with version control.

  • HBS simplifies 3-2-1 backup plans

    HBS centralizes backup, restoration, and synchronization for easily transferring data in the TS-h1283XU-RP to another QNAP NAS, remote server, or cloud storage space. HBS supports QuDedup technology that eliminates redundant data at the source and makes multi-version backup faster.

File transfer performance

Inline data compression helps boost QuTS hero data transfer performance. During simultaneous file transfer from multiple clients, inline data compression enabled QuTS hero performance is 1.6 times faster than QuTS hero or QTS without inline data compression.

10GbE connectivity optimizes high-speed data transfer

The TS-h1283XU-RP provides four Gigabit RJ45 ports, and also supports 10GbE connectivity with a pre-installed dual-port 10GbE RJ45 expansion card and a dual-port 10GbE SFP+ expansion card to satisfy bandwidth-demanding applications, including virtualization, large file sharing, and high-speed backup and recovery.

Abundant I/O capability with PCIe expansion

The TS-h1283XU-RP features 4 PCIe slots that enable using numerous expansion cards for expanding application potential.

Note: The 2U rackmount model uses low-profile graphics cards.

SSD caching to accelerate IOPS performance

Adding an SSD cache to the TS-h1283XU-RP is an easy method for increasing IOPS performance and reducing storage volume latency. It is perfect for IOPS-demanding applications, including databases and virtualization, and can significantly improve overall workflows. You can launch, stop, or change settings to meet your needs at any moment without shutting down the system.

Block-based iSCSI LUN: Ideal choice for virtualization storage

● Supports block-based iSCSI LUN as a high-performance, reliable, and affordable storage solution for VMware®, Citrix®, Microsoft® Hyper-V®, and Windows Server® 2019 virtualization environments.

● Supports VMware VAAI and Microsoft ODX to increase performance by offloading server loading for ESXi server and Hyper-V respectively, and supports QNAP vSphere Client plug-in with enhanced operational efficiency and management in virtualization applications.

All-in-one solution for hosting virtual machines and containers

Regardless of your virtualization needs, you can count on Virtualization Station and Container Station for comprehensive virtualization support. Coupled with Network & Virtual Switch app that boosts interoperability between virtual machines, containers, QNAP NAS, and other physical devices on the network, allowing you to flexibly allocate physical and virtual network resources to simplify network deployment.

  • Virtualization Station

    Run multiple Windows®, Linux®, UNIX®, and Android™ virtual machines and access them via a web browser or Virtual Network Computing (VNC). Businesses can run virtualized server applications on a single NAS without the need for additional physical servers.

  • Container Station

    Experience LXC and Docker® lightweight virtualization technologies, and download apps from the built-in Docker Hub Registry®, import or export containers, and create multiple microservices.

Complete backup planning

QNAP provides a reliable, flexible backup and disaster recovery solution to assist organizations in routine backup jobs cost-effectively and with high productivity.

  • HBS

    Consolidates backup, restoration and synchronization functions for easily transferring data to local, remote and cloud storage spaces as a comprehensive data storage and disaster recovery plan. QuDedup technology deduplicates backup data at the source to accelerate multi-version backups.

  • Snapshots

    Snapshots are essential for NAS data protection, and the block-level feature makes them a dependable method for protecting data in the face of growing ransomware threat. QuTS hero supports near-limitless snapshots to reinforce your multi-version backups.

  • VM backup

    With high performance, potentially huge storage capacities, integrated virtualization solutions, and snapshot support for recording the system state at any specific time, the TS-h1283XU-RP is perfect for backing up virtual machines.

Cloud Storage Gateway provides low latency access to data on the cloud

The TS-h1283XU-RP perfectly integrates NAS with mainstream cloud services. By deploying cloud storage gateways and enabling local caching on the NAS, you can seamlessly use the cloud for storage, backup, and data recovery with low-latency access, providing an innovative hybrid cloud experience.

  • HybridMount File-based Cloud Gateway

    Flexibly expand your storage capacity by connecting to the cloud storage. You can leverage QuTS hero apps to manage and edit your cloud files or monitor multimedia files. HybridMount is ideal for file server online collaboration and file-level data analysis.

  • VJBOD Cloud Block-based Cloud Gateway

    Supports mounting object cloud storage as a block-based volume or LUN on a NAS. Block-based data transmission uploads random data and large files to the cloud in blocks, and only block-based volume or LUN changes, such as addition, modification, or deletion will be transmitted. This is ideal for enterprise-level applications with large file transfer requirements, such as databases, VM volumes, and videos.

Build an affordable Fibre Channel SAN environment

Common Fibre Channel Storage Area Networks (SAN) devices are often costly. Now you have more budge-friendly options to easily add your NAS to a SAN environment. By installing a Marvell®, ATTO® or QNAP Fibre Channel card in the TS-h1283XU-RP, you can set a Fibre Channel Target using the iSCSI & Fibre Channel app. Moreover, the LUN Masking and Port Binding features provide an additional layer of data security.

Specifications

CPU Intel® Xeon® E E-2136 6-core / 12-thread processor
CPU Architecture 64-bit x86
Floating Point Unit
Encryption Engine  ✓(AES-NI)
System Memory 128 GB UDIMM DDR4 ECC (4 x 32GB)
Maximum Memory 128 GB (4 x 32 GB)
Memory Slot 4 x UDIMM DDR4
Flash Memory 5GB (Dual boot OS protection)
Drive Bay 12 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility 3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable
SSD Cache Acceleration Support
GPU pass-through
Gigabit Ethernet Port (RJ45) 4
10 Gigabit Ethernet Port 2 x 10GbE SFP+ SmartNIC port, 2 x 10GBase-T port
Wake on LAN (WOL)
Jumbo Frame
PCIe Slot 4
Slot 1: PCIe Gen 2 x4 (PCH)
Slot 2: PCIe Gen 3 x8 (CPU)
Slot 3: PCIe Gen 3 x4 (CPU)
Slot 4: PCIe Gen 3 x4 (CPU)
Slot 2 and slot 4 are preinstalled with 10GbE network adapters
Card dimensions for PCIe slot 1:220 x 68.9x 39.08 mm / 8.66 x 2.71 x 1.54 inches.
Card dimensions for PCIe slot 2~Slot 4:220 x 68.9x 18.76 mm / 8.66 x 2.71 x 0.74 inches.
Wider cards can be installed if the next PCIe slot will not be used.
USB 3.2 Gen 2 (10Gbps) Port 2 x Type-C USB 3.2 Gen 2 10Gbps
4 x Type-A USB 3.2 Gen 2 10Gbps
Form Factor 2U Rackmount
LED Indicators HDD 1-12, Status, LAN, storage expansion port status
Buttons Power, Reset
Dimensions (HxWxD) 88.3 × 482 × 562 mm
Weight (Net) 11.75 kg
Operating Temperature 0 - 40 °C (32°F - 104°F)
Storage Temperature -20 - 70°C (-4°F - 158°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit 300W(x2), PSU, 100-240V
Power Consumption: Operating Mode, Typical 105.12 W
Tested with drives fully populated.
Fan System fan: 2 x 60mm, 12VDC
System Warning Buzzer
Max. Number of Concurrent Connections (CIFS) - with Max. Memory 10000
