QNAP TS-h3077AFU-R5-32G 2U 30-bay 2.5" SATA all flash NAS AMD Ryzen 7600/Ryzen Pro 7645 6-core/12 thread processor up to 5.1 GHz32GB DDR5 non-ECC RAM 3 Yrs

QNAPSKU: TS-h3077AFU-R5-32G

Availability:

✅ In Stock at Supplier (ETA: Usually in 1-3 Business Days)

Price:
Sale price$9,467.00

Estimate shipping

Description

Overview

TS-h3077AFU
Highly reliable ZFS-based all-flash NAS with AMD Ryzen™ 7000 series processor – boosting all-round business with petabyte-scale storage and 100 GbE potential

Gain a competitive advantage by deploying an AMD Ryzen™ 7000 series-powered SATA SSD all-flash storage with 30 drive bays. The TS-h3077AFU is ideal for media production companies, enterprises, and science research institutions that require high-performance large capacity storage for storing recordings, business assets, Big Data, and virtual machines.

Optimized SSD performance
The QuTS hero operating system maximizes SSD performance and lifespan by featuring technologies such as inline data deduplication, QSAL (QNAP SSD Antiwear Leveling), and more.

2 x 10/2.5 GbE as standard and upgradable to 100 GbE
Upgrade to 100/25 GbE using a PCIe network card and accelerate virtualization, intensive file access, media file transfer, and large backup/restoration tasks.

Long-term and stable supply
The TS-h3077AFU will be available and supported by QNAP for an extended period, up to 2030.

Built-in GPU for graphics
Power-efficient AMD Radeon™ Graphics streamlines video editing/transcoding and simultaneously runs multiple tasks.

Petabyte-scale storage
Connect up to eight 24-bay JBODs (TL-R2400PES-RP) to attain petabyte-scale storage capacity of 192 drives.

DDR5 RAM
Uses industry-leading DDR5 RAM. Expandable to 192 GB for handling more tasks, and supports ECC memory.

QNAP TS-h1677AXU-RP-R7-32G Specifications
CPU AMD Ryzen™ 5 7000 series 6-core/12-thread processor, burst up to 5.1 GHz
AMD Radeon Graphics
CPU Architecture 64-bit x86
Graphic Processors AMD Radeon™ Graphics
Floating Point Unit
Encryption Engine  (AES-NI)
Hardware-accelerated Transcoding
System Memory 32 GB UDIMM DDR5 (1x 32 GB)
Maximum Memory 192 GB (4 x 48 GB)
Memory Slot 4 x UDIMM DDR5
Support optional ECC memory
Flash Memory 5GB (Dual boot OS protection)
Drive Bay 30 x 2.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility 2.5-inch SATA solid state drives
Hot-swappable
SSD Cache Acceleration Support
GPU pass-through
2.5 Gigabit Ethernet Port (2.5G/1G/100M) 2 (2.5G/1G/100M/10M)
10 Gigabit Ethernet Port 2 x 10GBASE-T (10G/5G/2.5G/1G/100M)
Wake on LAN (WOL)
Jumbo Frame
PCIe Slot 3
Slot 1: Gen 4 x 4
Slot 2: Gen 4 x 8 or Gen 4 x 4*
Slot 3: Gen4 x 4
*Slot 2 provides the width of PCIe Gen4 x8 when Slot 1 is not in use, and provides the width of PCIe Gen4 x4 when Slot 1 is in use.
Card dimensions for PCIe slot 1:250 x 111.15 x 18.76 mm / 9.84 x 4.38 x 0.74 inches
Card dimensions for PCIe slot 2:250 x 111.15 x 18.76 mm / 9.84 x 4.38 x 0.74 inches
Card dimensions for PCIe slot 3:200 x 111.15 x 23.76 mm / 9.84 x 4.38 x 0.94 inches
Wider cards can be installed if the next PCIe slot will not be used.
USB 3.2 Gen 2 (10Gbps) Port 2 x Type-A USB 3.2 Gen 2 10Gbps
Form Factor 2U Rackmount
LED Indicators Power Status, SSD 1-30, Status, LAN, storage expansion port status
Buttons Power, Reset
Dimensions (HxWxD) 88.3 × 442.6 × 485.2 mm
Excludes ear hook and the protruding part of the Power Supply Unit.
Weight (Net) 12.73 kg
Weight (Gross) 18.69 kg
Operating Temperature 0 - 40 °C (32°F - 104°F)
Storage Temperature -20 - 70°C (-4°F - 158°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit 550W(x2), 100-240V
Power Consumption: Operating Mode, Typical 380.23 W
Tested with drives fully populated.
Fan System fan: 3 x 60mm, 12VDC
System Warning Buzzer
Standard Warranty 5
Max. Number of Concurrent Connections (CIFS) - with Max. Memory 5000
