Description
Sophos XGS 136w Security Appliance -XY1DTCHAU
+
Sophos Xstream Protection - 39 MOS - XS136Z39ZZNCAA
XGS Series
Next-Gen Firewall Appliances
- Real-Time Threat Protection
- Easy and Flexible Deployment
- Single Point of Security Management
- Patented Layer-8 Identity control
- Service Length #: 39 months License
XGS Series Next-Gen Firewall Appliances
SMB and Branch Office: Desktop Models
Customers looking for an all-in-one network security solution will appreciate the seamless connectivity options available for our desktop appliances. With the modularity that smaller businesses, retail outlets, and branch offices need to grow and adapt to changing circumstances, they offer the perfect balance between price and performance. All desktop models are optionally available with built-in Wi-Fi.
All models are powered by a high-speed CPU plus a dedicated Xstream Flow Processor for hardware acceleration.
Performance |
|
Firewall | 11,500 Mbps |
TLS Inspection | 950 Mbps |
Firewall IMIX | 6,500 Mbps |
IPS | 4,000 Mbps |
IPsec VPN | 6,350 Mbps |
NGFW | 3,000 Mbps |
Threat Protection | 1,000 Mbps |
Latency (64 byte UDP) | 8 µs |
Connectivity |
|
Ethernet Interfaces (Fixed) | 10 x GE copper |
2 x SFP Fiber* | |
Power-over-Ethernet (Fixed) | 2 x 2.5 GE |
802.3at (30W max. per port) | |
Management Interfaces | 1 x COM RJ45 |
1 x COM Micro-USB | |
Other I/O Interfaces | 1 x USB 2.0 (front) |
1 x USB 3.0 (rear) | |
Wi-Fi Option (W-Model Only) | Wi-Fi 5 (802.11ac) |
3X3:3 MIMO | |
3 external antennas | |
Single radio, 2.4 or 5 GHz | |
Modularity |
|
Expansion Slots | 1 |
Optional Add-On Modules | 3G/4G module |
5G module | |
2nd Wi-Fi 5/802.11ac module (for w-model only) | |
SFP VDSL modem | |
SFP transceivers | |
Redundancy |
|
Swappable Components | Optional 2nd power supply |
Performance Test Methodology
General | Maximum throughput measured under ideal test conditions using industry standard Keysight-Ixia BreakingPoint test tools. Actual performance may vary depending on network conditions and activated services. |
Firewall | Measured using HTTP traffic and 512 KB response size |
Firewall IMIX | UDP throughput based on a combination of 66 byte, 570 byte and 1518 byte packet sizes |
IPS | Measured with IPS with HTTP traffic using default IPS ruleset and 512 KB object size. |
IPsec VPN | HTTP throughput using multiple tunnels and 512 KB HTTP response size |
TLS inspection | Performance measured with IPS with HTTPS sessions and different cipher suites. |
Threat Protection | Measured with Firewall, IPS, Application Control, and malware prevention enabled using HTTP 200 KB response size |
