StarTech.com POESLT1G48V PoE Splitter - 48 V DC Output - 1 x PoE+ Input Port(s) - 1 x Ethernet, 1 x Terminal Block Output Port(s)

StarTechSKU: POESLT1G48V

Availability:

🚚 In Stock at Supplier (ETA: Usually in 1-3 Business Days)

Pickup available at PC LAN Store

1-3 Business Days

Price:
Sale price$290.00
1

Estimate shipping

Description

StarTech POESLT1G48V PoE Splitter - 48 V DC Output - 1 x PoE+ Input Port(s) - 1 x Ethernet, 1 x Terminal Block Output Port(s)

Splits a PoE connection (max 90W) into separate data (RJ45) and DC power (terminal block) that can power any device that uses DC power between 12V-48VDC (1.5A). Power non-PoE devices using network infrastructure, where power is not available.

Power Non-PoE Devices

Perfect for using PoE to power older devices while also providing network access for monitoring and control applications. Applications include:

  • Security (card swipe or proximity boxes)
  • Environmental monitoring (temperature/moisture sensors)
  • Telco (analog interface systems/conversion)

Straightforward Deployment

Supports IEEE 802.3af (PoE / Type 1), IEEE 802.3at (PoE+ / Type 2), and IEEE 802.3bt (PoE++ / Type 3) PoE inputs up to 90W and splits data and power. Power output via terminal block can be configured for 12/16/24/48V DC (1.5A).

The configuration is completed by DIP switches and the product can be wall or DIN rail mounted using the included hardware.

Designed for Harsh Environments

  • Industrial features include -40 C to 75 C operating temperature, IP-30 rated housing, vibration, shock, and free-fall standard testing.
  • Vibration: EN 60068-2-6 Shock: EN 60068-2-27 Free-Fall: EN 60068-2-32
  • 600,000+ hours MTBF rating using Telcordia/Bellcore at 50 C for long-term reliability.
  • The POESLT1G48V is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Specification

Power Description
Minimum Output Voltage 12 V DC
Maximum Output Voltage 48 V DC
Interfaces/Ports
Input Ports 1 x PoE+
Output Ports 1 x Ethernet
1 x Terminal Block
Miscellaneous
REACH Declaration URL https://media.startech.com/cms/pdfs/poeslt1g48v_rohs.pdf
EU RoHS Declaration URL https://media.startech.com/cms/pdfs/poeslt1g48v_rohs.pdf
End of Life Manual Availability Yes
REACH free of SVHC Yes
WEEE Statement https://media.startech.com/cms/pdfs/poeslt1g48v_weee.pdf
Physical Characteristics
Weight (Approximate) 150 g
Form Factor DIN Rail/Wall Mountable
Length 104.1 mm
Height 33 mm
Width 81.3 mm
General Information
Product Type PoE Splitter
Manufacturer Part Number POESLT1G48V
Manufacturer Website Address http://www.startech.com/au
Packaged Quantity 1 Each
Manufacturer StarTech.com
Product Model POESLT1G48V
Product Name POESLT1G48V PoE Splitter
Brand Name StarTech.com
