High Density HD6500
Scalable high-density storage server for multi-petabyte applications
All the space you will ever need
With 60 bays in a 4U rackmount enclosure and support for up to 300 drives after expansion, the Synology HD6500 is the ideal high-density storage solution for large-scale warm and cold storage applications such as full system backups, video post-production, and large surveillance deployments.
CPU
2 x 10-core Intel Xeon Silver
Throughput
Over 6,688/6,662MB/s sequential read/write
Memory
64 GB DDR4 ECC, expandable to 512 GB
Scalability
Expand to 300 drives with four RX6025sas expansion units
Consistent performance at five times the size
The HD6500 is designed to scale up to 5 times in capacity with four additional RX6025sas expansion units. SAS multipath-enabled connectivity provides up to double the typical performance together and increased redundancy.
Built for high reliability
The HD6500 is built to keep mission-critical data and services accessible, so that businesses can continue to perform even when disaster strikes.
Powerful networking options
The HD6500 supports a large variety of networking interfaces, protocols, and configurations, whether you need fast sequential transfer, support for simultaneous connections, or high network redundancy.
Built-in fast connectivity
Three Gigabit Ethernet and two 10GbE RJ-45 ports allow for rapid transfer speeds right out of the box.
Mix and match network ports
Add extra 10GbE SFP+/RJ-45, 25GbE SFP28, or Fibre Channel ports in varying configurations by leveraging the four expansion slots.3
Failover and network balancing
Bond multiple network interfaces with Link Aggregation to enable automatic network failover and load balancing.
Consolidate your data storage
Back up your backup solutions, bring all your files together in one place, or bring distributed surveillance deployments under central control.
Massive file server
Host and retrieve massive files from extensive archives whenever needed. Provide user friendly access and set up powerful cross-site syncing.
A private cloud suite for file sharing
Synology Drive is a private cloud management and access solution that enables remote data access, synchronization, on-demand file restoration, and backup via desktop and mobile applications. Sync data between different platforms and devices, and access your organization’s files through mobile apps, desktop clients, and a browser-based interface. Set granular file and folder access and sharing permissions. Maintain a full overview of file activities and track file share settings changes with detailed records in the advanced Synology Drive Admin Console.
Cross-site syncing
Leverage SMB or NFS shares to provide efficient access to company files over the local network or VPN. Manage data access privileges with access control lists (ACL) though Active Directory/LDAP integration and protect files against tampering or removal with built-in snapshot technology.
Secure site-to site file and folder syncing
Make sure branches or teams always have up-to-date copies of crucial documents and data available locally by syncing folders one or two-way using Synology Drive ShareSync. Let your Synology systems update files across locations each time there is a change to efficiently keep all stakeholders on the same page.
Efficient cross-site syncing through the cloud
Securely synchronize files and data from the HD6500 to Synology systems across different sites or offices, and back, by leveraging hybrid cloud technology with Synology Hybrid Share.4 Synchronize large sets of data to the cloud, and leverage the powerful bandwidth of our data centers to stream requested files to local NAS deployed at branch offices, no matter their size. Frequently used files are kept stored on local NAS to provide users access at LAN speeds and can also be pinned manually to prevent them from being removed from the cache.
Central backup server
Protect large numbers of PCs, servers, Synology systems, and hypervisors, or back up your backup servers with a central storage solution.
Backup destination for shares and LUNs
Use Hyper Backup to back up files, LUNs, installed applications, and system configurations from tens or hundreds of Synology servers to your HD6500. Set and forget backup tasks with regular schedules, enhance security with fine-grained user permissions and encryption, reduce backup sizes with built-in deduplication, and restore data flexibly with multi-versioning.
Snapshot Replication enables configurable point-in-time snapshots of shared folders and LUNs with an RPO as low as 5 minutes and recovery within seconds.
Bare-metal backup for Synology NAS
Centrally manage bare-metal backups of all your Synology servers from a single centralized console on your HD6500. Leverage built-in deduplication technology to reduce backup sizes and multi-versioning to allow flexible restoration.
Scalable storage to store your growing backups
Safeguard your backups by storing backup copies in the HD6500 via ActiveProtect Vault without needing to drastically change your existing backup infrastructure.
Long-term backup storage for regulatory compliance
Store your backups with a secure and scalable storage solution that allows you to ensure compliance via long-term data retention.
Main surveillance storage
Manage distributed deployments of hundreds of local recording servers and thousands of IP cameras centrally.
Centralized, secure, and scalable surveillance
Flexible scaling and expansion
Connect up to 600 IP cameras5 from a selection of over 8,300 validated models to the HD6500 itself, or connect hundreds more by adding recording servers at the edge. Easily add storage as deployments grow.
Central management and recording
Manage up hundreds of Synology NAS or NVR recording servers from one host, store copies of all or some recordings centrally, and monitor all streams from one interface with Surveillance Station Centralized Management System.
Secure and private video storage
Admins can set detailed rules for who can check live streams or review recordings and footage can be protected against unauthorized access with industry-standard AES-256 encryption.
Anywhere access with multiple clients
Watch and analyze live streams or recordings from web browsers, desktop clients, or mobile apps.
Advanced deployment and analysis options
Batch and automated camera deployment
Automatically locate cameras within a set IP range or configure units in batch by importing spreadsheets and conveniently replicate settings to new cameras.
Instant event streaming on multi-location maps
Preview footage directly on multi-floor, multi-location maps when events are detected to stay on top of your deployment, with Google Maps and OpenStreetMap integration to make geographically spread-out deployments easier to monitor.
Dual recording, locally and to the cloud
Record each camera’s footage to two Synology servers simultaneously for added redundancy and instant access — for instance, to a smaller device at the edge and a larger central management server. Stream feeds directly to the cloud with C2 Backup for Surveillance for fast access and convenient sharing whenever you need evidence.4
Event detection and smart analytics options
Add support for deep learning-powered algorithms and detection profiles such as intrusion detection, license plate recognition, congestion alerts, and face recognition by joining Deep Learning NVR servers to your deployment.
Get more with DiskStation Manager
Take advantage of a host of native productivity, management, and security solutions available in the web-based Synology DSM operating system.
Central Management System
Conveniently manage your fleet of Synology NAS from a centralized console.
Security
Shield your Synology NAS from the most sophisticated threats with industry-leading security solutions.
Synology High Availability
Seamless transition between clustered servers in the event of a server failure to minimize the impact on applications.
High Density HD6500
Scalable high-density storage server for multi-petabyte applications
All the space you will ever need
With 60 bays in a 4U rackmount enclosure and support for up to 300 drives after expansion, the Synology HD6500 is the ideal high-density storage solution for large-scale warm and cold storage applications such as full system backups, video post-production, and large surveillance deployments.
CPU
2 x 10-core Intel Xeon Silver
Throughput
Over 6,688/6,662MB/s sequential read/write
Memory
64 GB DDR4 ECC, expandable to 512 GB
Scalability
Expand to 300 drives with four RX6025sas expansion units
Consistent performance at five times the size
The HD6500 is designed to scale up to 5 times in capacity with four additional RX6025sas expansion units. SAS multipath-enabled connectivity provides up to double the typical performance together and increased redundancy.
Built for high reliability
The HD6500 is built to keep mission-critical data and services accessible, so that businesses can continue to perform even when disaster strikes.
Powerful networking options
The HD6500 supports a large variety of networking interfaces, protocols, and configurations, whether you need fast sequential transfer, support for simultaneous connections, or high network redundancy.
Built-in fast connectivity
Three Gigabit Ethernet and two 10GbE RJ-45 ports allow for rapid transfer speeds right out of the box.
Mix and match network ports
Add extra 10GbE SFP+/RJ-45, 25GbE SFP28, or Fibre Channel ports in varying configurations by leveraging the four expansion slots.3
Failover and network balancing
Bond multiple network interfaces with Link Aggregation to enable automatic network failover and load balancing.
Consolidate your data storage
Back up your backup solutions, bring all your files together in one place, or bring distributed surveillance deployments under central control.
Massive file server
Host and retrieve massive files from extensive archives whenever needed. Provide user friendly access and set up powerful cross-site syncing.
A private cloud suite for file sharing
Synology Drive is a private cloud management and access solution that enables remote data access, synchronization, on-demand file restoration, and backup via desktop and mobile applications. Sync data between different platforms and devices, and access your organization’s files through mobile apps, desktop clients, and a browser-based interface. Set granular file and folder access and sharing permissions. Maintain a full overview of file activities and track file share settings changes with detailed records in the advanced Synology Drive Admin Console.
Cross-site syncing
Leverage SMB or NFS shares to provide efficient access to company files over the local network or VPN. Manage data access privileges with access control lists (ACL) though Active Directory/LDAP integration and protect files against tampering or removal with built-in snapshot technology.
Secure site-to site file and folder syncing
Make sure branches or teams always have up-to-date copies of crucial documents and data available locally by syncing folders one or two-way using Synology Drive ShareSync. Let your Synology systems update files across locations each time there is a change to efficiently keep all stakeholders on the same page.
Efficient cross-site syncing through the cloud
Securely synchronize files and data from the HD6500 to Synology systems across different sites or offices, and back, by leveraging hybrid cloud technology with Synology Hybrid Share.4 Synchronize large sets of data to the cloud, and leverage the powerful bandwidth of our data centers to stream requested files to local NAS deployed at branch offices, no matter their size. Frequently used files are kept stored on local NAS to provide users access at LAN speeds and can also be pinned manually to prevent them from being removed from the cache.
Central backup server
Protect large numbers of PCs, servers, Synology systems, and hypervisors, or back up your backup servers with a central storage solution.
Backup destination for shares and LUNs
Use Hyper Backup to back up files, LUNs, installed applications, and system configurations from tens or hundreds of Synology servers to your HD6500. Set and forget backup tasks with regular schedules, enhance security with fine-grained user permissions and encryption, reduce backup sizes with built-in deduplication, and restore data flexibly with multi-versioning.
Snapshot Replication enables configurable point-in-time snapshots of shared folders and LUNs with an RPO as low as 5 minutes and recovery within seconds.
Bare-metal backup for Synology NAS
Centrally manage bare-metal backups of all your Synology servers from a single centralized console on your HD6500. Leverage built-in deduplication technology to reduce backup sizes and multi-versioning to allow flexible restoration.
Scalable storage to store your growing backups
Safeguard your backups by storing backup copies in the HD6500 via ActiveProtect Vault without needing to drastically change your existing backup infrastructure.
Long-term backup storage for regulatory compliance
Store your backups with a secure and scalable storage solution that allows you to ensure compliance via long-term data retention.
Main surveillance storage
Manage distributed deployments of hundreds of local recording servers and thousands of IP cameras centrally.
Centralized, secure, and scalable surveillance
Flexible scaling and expansion
Connect up to 600 IP cameras5 from a selection of over 8,300 validated models to the HD6500 itself, or connect hundreds more by adding recording servers at the edge. Easily add storage as deployments grow.
Central management and recording
Manage up hundreds of Synology NAS or NVR recording servers from one host, store copies of all or some recordings centrally, and monitor all streams from one interface with Surveillance Station Centralized Management System.
Secure and private video storage
Admins can set detailed rules for who can check live streams or review recordings and footage can be protected against unauthorized access with industry-standard AES-256 encryption.
Anywhere access with multiple clients
Watch and analyze live streams or recordings from web browsers, desktop clients, or mobile apps.
Advanced deployment and analysis options
Batch and automated camera deployment
Automatically locate cameras within a set IP range or configure units in batch by importing spreadsheets and conveniently replicate settings to new cameras.
Instant event streaming on multi-location maps
Preview footage directly on multi-floor, multi-location maps when events are detected to stay on top of your deployment, with Google Maps and OpenStreetMap integration to make geographically spread-out deployments easier to monitor.
Dual recording, locally and to the cloud
Record each camera’s footage to two Synology servers simultaneously for added redundancy and instant access — for instance, to a smaller device at the edge and a larger central management server. Stream feeds directly to the cloud with C2 Backup for Surveillance for fast access and convenient sharing whenever you need evidence.4
Event detection and smart analytics options
Add support for deep learning-powered algorithms and detection profiles such as intrusion detection, license plate recognition, congestion alerts, and face recognition by joining Deep Learning NVR servers to your deployment.
Get more with DiskStation Manager
Take advantage of a host of native productivity, management, and security solutions available in the web-based Synology DSM operating system.
Central Management System
Conveniently manage your fleet of Synology NAS from a centralized console.
Security
Shield your Synology NAS from the most sophisticated threats with industry-leading security solutions.
Synology High Availability
Seamless transition between clustered servers in the event of a server failure to minimize the impact on applications.
| Model | HD6500 |
| CPU | Intel Xeon Silver 4210R, 10-core 2.4 GHz (Turbo up to 3.2 GHz) |
| Memory | 64 GB DDR4 ECC RDIMM (expandable up to 512 GB) |
| Drive Bays | 60 × 3.5"/2.5" SATA HDD/SSD (expandable to 300 bays with 4× RX6022sas) |
| Max Raw Capacity | Up to 4.8 PB |
| Storage Interface | SATA 6Gb/s |
| Network Ports | 2 × 10GbE RJ-45, 4 × 1GbE RJ-45 |
| PCIe Expansion | 2 × PCIe Gen 3 x8 slots |
| USB Ports | 2 × USB 3.2 Gen 1 |
| Expansion Ports | 4 × Mini-SAS HD (for RX6022sas) |
| RAID Support | RAID 0, 1, 5, 6, 10, F1, JBOD |
| File System | Btrfs, EXT4 |
| Operating System | Synology DiskStation Manager (DSM) |
| Performance | Up to 6,688 MB/s sequential read, 6,662 MB/s write |
| Virtualization | VMware, Citrix, Microsoft Hyper-V, OpenStack |
| High Availability | Supports Synology High Availability (active-passive clustering) |
| Management | Out-of-band (OOB) management port |
| Dimensions (H × W × D) | 132.3 × 447 × 692 mm (4U rackmount) |
| Weight | 17.8 kg (without drives) |
| Power Supply | 2 × 800W redundant PSU |
| Operating Temperature | 5°C to 35°C |
| Certifications | FCC, CE, BSMI, VCCI, RCM, UKCA |
| Warranty | 5 years |
