Description
Overview
Archer BE550 Pro
BE9700 Tri-Band Wi-Fi 7 Router
- Blazing-Fast 9.7 Gbps Tri-Band Wi-Fi: Wi-Fi 7 unleashes the full potential of the 6 GHz band with up to 320 MHz channels and 9.7 Gbps Wi-Fi speeds. Enjoy full access to 8K streaming and high-speed downloading.†◇
- Faster than Wi-Fi 6E: Multi-Link Operation (MLO) enables Archer BE550 Pro to transmit data with Wi-Fi 7 clients across the 6 GHz, 5 GHz and 2.4 GHz bands simultaneously, delivering faster Wi-Fi speeds than Wi-Fi 6/6E routers.‡◇
- 4× Lower Latency with Minimal Buffering: Significantly lower latency than Wi-Fi 6/6E routers enables emerging applications like VR/AR, video conferencing, and online gaming to always run at top performance.△
- Higher Capacity for More Devices: Communicates with multiple devices and tri-band simultaneously. Combined with the powerful CPU, Wi-Fi 7 provides congestion-free signals to your laptop, TV, thermostat, and baby monitor.
- EasyMesh-Compatible: Works with EasyMesh routers and range extenders to form seamless whole home Mesh Wi-Fi, preventing drops and lag when moving between signals.***
- TP-Link HomeShield: Enhanced security defends against the latest cyber threats.*
Archer BE550 Pro
BE9700 Tri-Band Wi-Fi 7 Router
- Blazing-Fast 9.7 Gbps Tri-Band Wi-Fi: Wi-Fi 7 unleashes the full potential of the 6 GHz band with up to 320 MHz channels and 9.7 Gbps Wi-Fi speeds. Enjoy full access to 8K streaming and high-speed downloading.†◇
- Faster than Wi-Fi 6E: Multi-Link Operation (MLO) enables Archer BE550 Pro to transmit data with Wi-Fi 7 clients across the 6 GHz, 5 GHz and 2.4 GHz bands simultaneously, delivering faster Wi-Fi speeds than Wi-Fi 6/6E routers.‡◇
- 4× Lower Latency with Minimal Buffering: Significantly lower latency than Wi-Fi 6/6E routers enables emerging applications like VR/AR, video conferencing, and online gaming to always run at top performance.△
- Higher Capacity for More Devices: Communicates with multiple devices and tri-band simultaneously. Combined with the powerful CPU, Wi-Fi 7 provides congestion-free signals to your laptop, TV, thermostat, and baby monitor.
- EasyMesh-Compatible: Works with EasyMesh routers and range extenders to form seamless whole home Mesh Wi-Fi, preventing drops and lag when moving between signals.***
- TP-Link HomeShield: Enhanced security defends against the latest cyber threats.*
| TP-Link Archer BE550 Pro Specifications | |
|---|---|
| Wireless | |
| WiFi Speeds | BE9700 • 6 GHz: 5764 Mbps (802.11be) • 5 GHz: 2882 Mbps (802.11be) • 2.4 GHz: 1032 Mbps (802.11be) |
| WiFi Range | 4 Bedroom Houses 6× Optimally Positioned Antennas Signal-boosting array for wide coverage |
| Beamforming | ✓ |
| High-Power FEM | ✓ |
| WiFi Capacity | High (Tri-Band) |
| OFDMA | ✓ |
| Airtime Fairness | ✓ |
| DFS | ✓ |
| Working Modes | Router Mode, Access Point Mode |
| Advanced Features | Multi-Link Operation (MLO) 320 MHz Channel 4K-QAM Multi-RUs EasyMesh-Compatible Alexa & Google Assistant Support IoT Network |
| Security | |
| Network Security | SPI Firewall Access Control IP & MAC Binding Application Layer Gateway |
| HomeShield Security | Real-Time IoT Protection Malicious Site Blocker Intrusion Prevention System DDoS Attack Prevention Home Network Scanner |
| Guest Network | • 1× 6 GHz • 1× 5 GHz • 1× 2.4 GHz |
| VPN Server | OpenVPN, PPTP, L2TP, WireGuard |
| VPN Client | OpenVPN, PPTP, L2TP, WireGuard |
| WiFi Encryption | WPA, WPA2, WPA3, WPA/WPA2-Enterprise (802.1x) |
| Hardware | |
| Ethernet Ports | • 1× 10 Gbps WAN/LAN • 1× 2.5 Gbps WAN/LAN • 3× 2.5 Gbps LAN |
| USB Support | 1× USB 3.0 Partition Formats: NTFS, exFAT, HFS+, FAT32 Functions: FTP Server, Media Server, Samba Server |
| Buttons | Power, Wi-Fi, LED, WPS, Reset |
| Power | 12 V ⎓ 3.3 A |
| Software | |
| Protocols | IPv4, IPv6 |
| Service Kit | HomeShield |
| EasyMesh | ✓ |
| Parental Controls | Custom Profiles Content Filter Library Family Time, Bedtime, Off Time Time Rewards Online Time Ranking Pause Internet Weekly/Monthly Reports |
| WAN Type | Dynamic IP, Static IP, PPPoE, PPTP, L2TP |
| Quality of Service | QoS by Device |
| Cloud Service | Auto Firmware Upgrade, TP-Link ID, DDNS |
| NAT Forwarding | Port Forwarding, Triggering, DMZ, UPnP |
| IPTV | IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN |
| DHCP | Reservation, Client List, Server |
| DDNS | TP-Link, NO-IP, DynDNS |
| Management Features | Tether App, Webpage |
| Other | |
| System Requirements | IE 11+, Firefox 12+, Chrome 20+, Safari 4+ JavaScript-enabled browser Cable/DSL modem ISP subscription |
| Certifications | CE, FCC, RoHS |
| Environment | Operating Temp: 0–40°C (32–104°F) Operating Humidity: 10–90% non-condensing |
| Physical | |
| Dimensions (W × D × H) | 76 × 231.7 × 203 mm (3.0 × 9.1 × 8.0 in) |
| Package Content | • Archer BE550 Pro Router • Power Adapter • RJ45 Ethernet Cable • Quick Installation Guide |
