TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch

TP-LinkSKU: TL-SF1016D

  • Ports: 16× 10/100Mbps Auto-Negotiation RJ45 ports
  • Switching Features: Auto MDI/MDIX support
  • PoE Ports: 4× IEEE 802.3af-compliant PoE ports
  • PoE Output: Up to 15.4W per port, 66W total PoE budget
  • Energy Saving: Green Ethernet technology reduces power consumption
  • Flow Control: IEEE 802.3x support for reliable data transmission
  • Design: Plastic housing with desktop or wall-mount installation
  • Deployment: Plug and Play with no configuration or installation required

Availability:

🚚 In Stock at Supplier (ETA: Usually in 1-3 Business Days)

Pickup available at PC LAN Store

1-3 Business Days

Price:
Sale price$52.00
1

Estimate shipping

Description

TP-Link TL-SF1016D 16-Port 10/100Mbps Desktop Switch



What This Product Does
The TL-SF1016D Fast Ethernet Switch is designed for SOHO (Small Office/Home Office) or workgroup users. All 16 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SF1016D can save up to 80%* of the power consumption and 70% of the packaging material can be recycled, making it an eco-friendly solution for your business network.

High Performance
TL-SF1016D Fast Ethernet Switch provides 16 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. Featuring non-blocking switching architecture, TL-SF1016D forwards and filters packets at full wire-speed for maximum throughput. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1016D work reliably.

TP-LINK Green Technology
This new generation TL-SF1016D Fast Ethernet Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.

It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials. Besides, 70% of the packaging material can be recycled.

Easy to Use
The auto features of this switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance.



Specifications

HARDWARE FEATURES
Interface 16× 10/100 Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Fan Quantity Fanless
Physical Security Lock No
External Power Supply External Power Adapter(Output: 5.0VDC / 0.6A)
Mac Address Table 2K
Dimensions ( W x D x H ) 7.9 x 5.6 x 1.6 in.
(200 x 142 x 40 mm)
Max Power Consumption 3.2W
Max Heat Dissipation 11.0 BTU/h
SOFTWARE FEATURES
Transfer Method Store and Forward
Advanced Functions Green Technology,
802.3X Flow Control,
OTHERS
Certification FCC, CE, RoHs
Package Contents 16-Port 10/100Mbps Desktop Switch TL-SF1016D
Power Adapter
User Guide
Environment Operating Temperature: 0℃~40℃ (32℉~104℉);
Storage Temperature: -40℃~60℃ (-40℉~140℉);
Operating Humidity: 10%~90% non-condensing;
Storage Humidity: 5%~90% non-condensing
