Overview
Access Ultra
UA-Ultra
An access reader with a built-in hub for complete, single-door entry control from one device.
Note. Not compatible with standalone Access Hubs.
Access Ultra
UA-Ultra
An access reader with a built-in hub for complete, single-door entry control from one device.
Note. Not compatible with standalone Access Hubs.
| UA-Ultra Specifications | |
|---|---|
| Dimensions | 126 × 45 × 37.45 mm (4.9 × 1.8 × 4.5") |
| NFC Card & Keyfob Access | ✓ |
| Mobile Unlock | ✓ |
| NDAA Compliant | ✓ |
| UL 294 Level | Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I |
| Tamper Switch | ✓ |
| Weatherproofing | IP55 |
| Weight | 140 g (4.9 oz) |
| Enclosure Material | Polycarbonate, aluminum alloy |
| Mount Material | Stainless steel |
| Mounting | Wall mount, gang box mount (Included) Junction box (Optional) |
| Indoor and Outdoor Use | Yes |
| Ambient Operating Temperature | -30 to 40° C (-22 to 104° F) |
| Ambient Operating Humidity | 5 to 90% noncondensing |
| Networking Interface | (1) 10/100 MbE RJ45 port |
| Connectivity | BLE 4.2, Ethernet |
| Power Method | PoE+ |
| Power Supply Standards | UL 294 Power-limited Class 2 PSU UL 60950-1 / 62368-1 LPS / PS2 PSU |
| Max. Power Consumption | 18W |
| Supported Voltage Range | 44–57V DC |
| ESD/EMP Protection | Air: ±8kV, Contact: ±4kV |
| Speaker | ✓ |
| LEDs | R/G/B/W |
| Button | (1) Factory-reset |
| NFC Frequency | 13.56 MHz |
| NFC Read Range | < 50 mm (1.95") |
| NFC Technology | ISO 14443A, 14443B, 15693 NFC Tag Types 1–5 MIFARE Classic, Plus, Ultralight, DESFire |
| PoE Cabling Requirements | Minimum: Cat 5e Patch cords: 26 AWG (0.13 mm²) Horizontal/riser cable: 24 AWG (0.21 mm²) |
| UL 294 Statement | IEEE 802.3 compliance not verified under UL 294. Designed to meet NEC Article 725.121 for Class 2/3 circuits. |
| CAN/ULC-60839-11-1 Grade | Grade I |
| Certifications | CE, FCC, IC, Anatel, SRRC, UL 294, CAN/ULC-60839-11-1 |
| Document Reference | UA-Ultra, V01 |
| Management Application | UniFi Access |
| Software Information | Version details available at unifi.ui.com |
