Description
Overview
G6 PTZ
UVC-G6-PTZ-B
All-weather, 4K dual-lens camera with 10x hybrid zoom, 1/1.8" 8MP image sensor, Multi-TOPS AI Engine, and ultra-low latency pan-tilt-zoom control for motion tracking.
G6 PTZ
UVC-G6-PTZ-B
All-weather, 4K dual-lens camera with 10x hybrid zoom, 1/1.8" 8MP image sensor, Multi-TOPS AI Engine, and ultra-low latency pan-tilt-zoom control for motion tracking.
PTZ Camera Specifications | |
---|---|
Dimensions | Without mount: Ø107.2 × 104.5 × 203.2 mm (Ø4.2 × 4.1 × 8") With mount: Ø107.2 × 111 × 230.2 mm (Ø4.2 × 4.8 × 9.1") |
IR Night Vision | 30 m (98 ft) |
Zoom Mode | 10x Hybrid |
Face Recognition | ✓ |
License Plate Recognition | ✓ |
Smart Detections | People, Vehicles, Animals |
Resolution | 4K |
Field of View | Wide: H: 109.9°, V: 56.7°, D: 134.1° Tele: H: 26.6°, V: 15.1°, D: 30.4° |
Pan-Tilt Range | Pan: 350°, Tilt: 100° |
Audio | Two-way audio |
Weatherproofing | IP66 |
Tamper Resistance | IK04 |
Mounting | Included: Wall, Surface, Ceiling, Pole mount Optional: Corner, In-Ceiling, Pendant mount, Conduit adapter |
UniFi Application Suite | Protect ✓ |
Networking Interface | 10/100 MbE RJ45 port |
Image Settings | Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR |
Max. Frame Rate | 30 FPS |
Resolution | 8MP 3840 × 2160 (16:9) |
Sensor | Wide: 1/1.8" 8MP Tele: 1/1.8" 8MP |
Lens | Wide: F 4.46 mm; ƒ/1.65 Tele: F 16.3 mm; ƒ/2.4 |
Night Mode | Built-in IR LED illumination and IR cut filter |
Max. Power Consumption | 24.5 W |
Supported Voltage Range | 42.5–57V DC |
Power Method | PoE+ |
Processor | Quad-core Arm® Cortex®-A53 based chip |
Pole Mount Diameter | 1.5–2" (38–50 mm) |
Weight | Without arm mount: 1 kg (2.2 lb) With arm mount: 1.1 kg (2.4 lb) |
Enclosure Material | Aluminum alloy, polycarbonate |
Mount Material | Arm mount: polycarbonate Pole mount: aluminum alloy |
Expansion Slot | MicroSD card |
Button | (1) Factory-reset |
Ambient Operating Temperature | -30 to 50° C (-22 to 122° F) |
Ambient Operating Humidity | 20 to 90% noncondensing |
NDAA Compliant | ✓ |
Certifications | CE, FCC, IC |
