SuperLink
UP-SuperLink
Proprietary super long-range, low-latency wireless gateway for UniFi Protect Sensors.
Note. SuperLink sensors are coming soon.
Long-range BLE coverage is comparable to WiFi coverage
SuperLink
UP-SuperLink
Proprietary super long-range, low-latency wireless gateway for UniFi Protect Sensors.
Note. SuperLink sensors are coming soon.
Long-range BLE coverage is comparable to WiFi coverage
| UP-SuperLink Specifications | |
|---|---|
| Dimensions | With antenna: 159.3 × 81.9 × 26 mm (6.3 × 3.2 × 1") With DIN rail mount: 159.3 × 81.9 × 38.5 mm (6.3 × 3.2 × 1.5") With wall mount: 159.3 × 81.9 × 30.5 mm (6.3 × 3.2 × 1.2") |
| Weight | 179 g (6.3 oz) |
| Enclosure Material | Polycarbonate, aluminum alloy |
| Mounting Material | Polycarbonate |
| Mounting Options | Wall, DIN rail |
| Networking Interface | (1) 10/100 MbE RJ45 port |
| Management Interface | Bluetooth® 5.2, SuperLink (proprietary) |
| Power Method | PoE; optional USB Type-C (5V, 1A) |
| Max. Power Consumption | 3.4W |
| ESD/EMP Protection | Air: ±8kV, Contact: ±4kV |
| Antenna Gain | Bluetooth: 3 dBi SuperLink: 1 dBi |
| Max. TX Power | Bluetooth: 10 dBm SuperLink: 27 dBm |
| Max. Client Count | Bluetooth: 7 SuperLink: 96* |
| LED | (1) Blue/white status indicator |
| Button | (1) Factory reset |
| Operating Temperature | 0 to 40° C (32 to 104° F) |
| Operating Humidity | 10 to 90% noncondensing |
| Certifications | FCC, IC, CE |
| NDAA Compliant | ✓ |
| Management Platform | UniFi Protect Web App UniFi Protect Mobile App (iOS™ and Android™) |
