Fiber WiFi 6
UF-WiFi6
GPON customer-premises equipment (CPE) with WiFi6 support.
Fiber WiFi 6
UF-WiFi6
GPON customer-premises equipment (CPE) with WiFi6 support.
| UF-WiFi6 Specifications | |
|---|---|
| Mechanical | |
| Dimensions | 140.8 × 141.5 × 31.7 mm (5.5 × 5.6 × 1.3") |
| Weight | 415 g (14.6 oz) |
| Enclosure Material | UV-stabilized polycarbonate (PC110U) |
| Hardware | |
| Processor | Dual-core MIPS 1004Kc @ 900 MHz |
| Memory | 256 MB RAM |
| Networking Interfaces | (1) SC/APC ITU-G.984 GPON WAN port (4) GbE RJ45 LAN ports |
| WiFi Standard | 802.11ax (WiFi 6), dual-band 2.4/5 GHz |
| MIMO | 2×2 (2.4 GHz and 5 GHz) |
| Max WiFi Radio Rate | 2.4 GHz: 300 Mbps / 5 GHz: 1.2 Gbps |
| Antenna Gain | 2.4 GHz: 1 dBi / 5 GHz: 3 dBi |
| Max WiFi TX Power | 20 dBm (both bands) |
| Optical Interface | |
| TX Wavelength | 1310 nm |
| RX Wavelength | 1490 nm |
| TX Power Range | 0.5 to 5 dBm |
| RX Sensitivity | -8 to -28 dBm |
| Downstream Rate | 2.488 Gbps |
| Upstream Rate | 1.244 Gbps |
| Physical Reach | Up to 20 km |
| Power | |
| Power Method | USB-C 5V DC, 3A Passive PoE 2-pair (4,5+; 7,8−) |
| Power Supply | 5V DC, 3A adapter with 1.5 m cord (included) |
| Supported Voltage Range | 10–30V DC (PoE) / 5V DC (adapter) |
| Max Power Consumption | 11W |
| Environmental | |
| Operating Temperature | -15 to 45°C (5 to 113°F) |
| Operating Humidity | 10 to 90% noncondensing |
| Software & Features | |
| Operating Mode | ONU/ONT Layer 2/3 Ethernet switch |
| Services | Web server, telnet, NAT, bridging/routing, firewall, application passthrough |
| Utilities | Dashboard, monitoring, alarms, logs |
| Security | GEM Port Encryption, WPA/WPA2/WPA3 |
| Management Interface | UISP Mobile App, Ethernet In-Band PON |
| Minimum Software Requirements | Modern web browser / iOS™ or Android™ |
| LED Indicators | |
| PON Status | 1× orange: signal too low 1–3× white: signal strength 3× orange: no signal Mixed: signal too strong or unauthorized |
| Ethernet | Steady white: link / Blinking: activity |
| Power | White: ON |
| Compliance | |
| Certifications | FCC, IC, CE |
| NDAA Compliant | ✓ |
