Ubiquiti U
Overview
PowerAmp
UPL-Amp-B
Premium speaker amplifier designed for high-fidelity multi-zone audio streaming and immersive spatial sound experiences.
PowerAmp
UPL-Amp-B
Premium speaker amplifier designed for high-fidelity multi-zone audio streaming and immersive spatial sound experiences.
| UPL-Amp-B Specifications | |
|---|---|
| Product Type | 2.1-Channel Integrated Streaming Amplifier |
| Color | Black |
| Amplifier Class | Class D |
| Audio Output | Stereo + Subwoofer (2.1) |
| Streaming Support | AirPlay 2, Spotify Connect, Soundtrack Your Brand |
| Multi-Zone Grouping | Up to 32 PowerAmps |
| Power Output | 130W per channel @ 8Ω, 1 kHz, < 0.05% THD+N 260W per channel @ 4Ω, 1 kHz, < 0.09% THD+N |
| Surround Format Support | Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, Dolby Digital Stereo PCM, Multichannel PCM |
| Audio Inputs | (1) HDMI eARC (2) RCA analog (L/R) |
| Audio Outputs | (2) Speaker terminals (banana plug) (1) RCA subwoofer output |
| Networking Interfaces | (2) GbE RJ45 ports |
| Wi-Fi Standards | 802.11 a/b/g/n/ac (Wi-Fi 5) |
| Wi-Fi Bands | 2.4 GHz: BW 20/40 MHz 5 GHz: BW 20/40/80 MHz |
| Display | 1.43" rotary knob with touchscreen |
| Button | (1) Factory-reset |
| Power Method | Universal AC input, 100–240V AC, 2.5A Max, 50/60 Hz |
| Max. Power Consumption | 17W |
| Dimensions (with knob) | 217 × 236.8 × 63.7 mm (8.5 × 9.3 × 2.5") |
| Dimensions (without knob) | 217 × 217 × 63.7 mm (8.5 × 8.5 × 2.5") |
| Weight | 2.4 kg (5.3 lb) |
| Enclosure Material | Polycarbonate (chassis), Aluminum (knob) |
| Mounting | Compact desktop; rack-compatible (2 side-by-side) |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 5 to 90% noncondensing |
| NDAA Compliant | ✓ |
| Certifications | FCC, IC, CE |
| Management App | UniFi Play (iOS & Android) |
| App Features | Setup, remote control, zone grouping |
PL-AMP-B PowerAmp, Black, Premium Speaker Amplifier
